Note:
You can create a one-second clip containing color bars and a 1-kHz tone, as a reference for calibrating video and audio equipment.
1. In the Project panel, click the New Item button
at the bottom of the Project panel and choose Bars And Tone.
2. In the New Synthetic dialog box, set Width, Height, Timebase, Pixel Aspect Ratio, and Sample Rate to match these same settings for the
sequence in which you will use the bars and tone. Click OK.
Some audio workflows must be calibrated at a specific tone level. The default level of the 1-kHz tone is -12 dB referenced to 0 dBFS. You
can customize the tone level to match your audio workflow by choosing Clip > Audio Options > Audio Gain with a clip selected. If you select the
bars and tone clip in the Project panel, you set the default gain level for new clip instances. If you select a clip in a Timeline panel, you change the
level for that clip instance only.
Franklin McMahon created
synthetic media: transparent video, color bars and tone, and color matte on the Layers Magazine
website.
Create HD color bars and a 1-kHz tone
Premiere Pro has HD color bars that comply with ARIB STD-B28 standard for calibrating video output. Synthetic media also include a 1-kHz tone.
For HD bars and tone, do the following:
1. Choose File > New > HD Bars and Tone.
2. A dialog launches with settings based on the existing sequence. Change settings, or click OK to accept the settings.
In
by Todd Kopriva and video2brain, you'll learn about the new HD color bars and tone, which comply with ARIB STD-B28, and how you
can use them in a sequence for output calibration.
Create black video
Empty areas of a track appear black if no other visible clip areas are present on underlying video tracks. If necessary, you can also create clips of
opaque black video for use anywhere in a sequence. A black video clip behaves as a still image. To create a clip of a different color, use a color
matte. (See
1. In the Project panel, click the New Item button
at the bottom of the Project panel and choose Black Video.
2. If necessary, in the New Black Video dialog box, set Width, Height, Timebase, and Pixel Aspect Ratio to match these settings for the
sequence in which you will use the black video clip. By default, the duration of the new clip is set to five seconds. Click OK.
You can change the default duration of black video clips and other still image clips in the General pane of the Preferences dialog box. For
more information, see
.
Create a color matte
1. In the Project panel, click the New Item button
at the bottom of the Project panel and choose Color Matte.
2. In the New Synthetic dialog box, set Width, Height, Timebase, and Pixel Aspect Ratio to match these settings for the sequence in which you
will use the color matte. Click OK.
3. In the Color Picker, select a color for the color matte, and click OK.
323
