Westermo OS Management Guide
Version 4.17.0-0
Use command ”filter” if a splitter is used, and ”no filter” if no splitter
is used.
Use ”show filter” to show the xDSL port’s filter setting.
Default values ”filter” (i.e., an external splitter is assumed by default)
11.3.4 Configure ADSL/ATM encapsulation type
Syntax [no] encap <llc|vcmux>
Context xDSL Port Configuration context (only available when ADSL mode is
used, see section 11.3.2 )
Usage Specify whether bridged LLC or bridged VC-MUX ATM encapsulation is
used. What encapsulation option to use depends on your ADSL provider.
Use command ”llc” to use bridged LLC and ”vcmux” to use bridged VC-
MUX encapsulation.
Use ”no encap” to reset the encapsulation mode to the default setting.
Use ”show encap” to show the xDSL port’s ADSL/ATM encapsulation setting.
Default values ”llc”
11.3.5 Configure ADSL/ATM VPI and VCI
Syntax [no] pvc <VPI/VCI>
Context xDSL Port Configuration context (only available when ADSL mode is
used, see section 11.3.2 )
Usage Specify the VCI and VPI used for the ATM PVC by your ADSL provider.
Some examples: ”pvc 0/38” is common in U.K., ”1/32” is common in Ger-
many, while ”pvc 8/35” is common for many other ADSL providers inside
and outside Europe.
Use ”no pvc” to reset the PVC to use default VPI/VCI. (In future versions of
WeOS the use of ”no pvc”, as well as the default PVC setting, may change.)
Use ”show pvc” to show the ATM PVC setting, i.e., which VPI and VCI are
configured.
