thus this use case cannot be configured via the Web interface. However,
a similar service can be achieved via the trusted peer use case, see
sec-
tion 35.1.7.3 .
❼ For comments on other settings, see the related example in
section 35.1.7.1 .
Example
Alice’s Configuration Bob’s Configuration
tunnel tunnel
ipsec 0 ipsec 0
enable enable
no aggressive no aggressive
pfs pfs
no ike no ike
no esp no esp
no peer peer 10.10.1.2
no outbound no outbound
local-id dn "C=US, O=ACME, CN=Alice" local-id dn "C=US, O=FOOBAR, CN=Bob"
remote-id dn "C=US, O=FOOBAR, CN=*" remote-id dn "C=US, O=ACME, CN=Alice"
local-subnet 10.0.1.0/24 local-subnet 10.0.2.128/29
remote-subnet 10.0.2.0/24 shared remote-subnet 10.0.1.0/24
method cert method cert
local-cert AliceCert local-cert BobCert
no remote-cert no remote-cert
remote-ca dn "C=US, O=FOOBAR, CN=FoobarCA" remote-ca dn "C=US, O=ACME, CN=AcmeCA"
no initiator initiator
dpd-action clear dpd-action restart
dpd-delay 30 dpd-delay 30
dpd-timeout 120 dpd-timeout 120
sa-lifetime 28800 sa-lifetime 28800
ike-lifetime 3600 ike-lifetime 3600
end end
end end
35.1.7.3 IKE with trusted peer certificates
As an alternative to installing trusted CA certificates, Alice and Bob can import
each others certificates and use as trusted peers.
In this user scenario, a VPN unit such as Alice will have to upload/import
❼ Bob’s certificate (BobCert),
❼ her own certificate (AliceCert), and
❼ the private key associated with her certificate.
In most cases Alice would also import her CA certificate (CA
A
), although this is not
required for this trust model. Typically she would then upload/import her private
