Westermo RedFox Series User Manual
Page 69
Westermo OS Management Guide
Version 4.17.0-0
❼ RFC4836 MAU MIB: The dot3IfMauBasicGroup and dot3IfMauAutoNegGroup
of the MAU MIB are supported.
❼ RFC3635 Ether-like Interface MIB: The dot3StatsTable is supported, enabling
monitoring of various error counters for Ethernet ports.
❼ RFC4133 Entity MIB: The entityPhysical group of the Entity MIB is supported.
It can be used to read unit serial number, firmware version, etc.
❼ RFC3433 Entity Sensor MIB: The Entity Sensor MIB can be used to monitor
the status of unit sensors for temperature, power supply, and ”digital-in”,
etc.
❼ RFC 4319 HDSL2/SHDSL MIB: On products with SHDSL ports, the
hdsl2ShdslSpanConfTable, hdsl2ShdslSpanStatusTable,
hdsl2ShdslInventoryTable and hdsl2ShdslSpanConfProfileTable are supported
(read-only).
❼ RFC 3621 Power Ethernet MIB: The PoE MIB is supported on products with
PoE ports.
❼ IEEE 802.1AB LLDP MIB
❼ RFC2787 VRRPv2 MIB: The vrrpOperations group is supported (read-only).
❼ RFC6527 VRRPv3 MIB: The vrrpv3Operations group is supported (read-only).
6.1.5.2
Private MIB
To use the WeOS private MIB, two Westermo specific MIB files should be loaded
into your SNMP management software (see
for information on rec-
ommended management software):
❼ WESTERMO-MIB: Defines the top level objects of the Westermo Private MIB
name space.
❼ WESTERMO-WEOS-MIB: Defines the WeOS branch of the Westermo Private
MIB.
6.1.6
Recommended Management Software
The following SNMP managers are recommended:
➞ 2015 Westermo Teleindustri AB
69
