Context
context (only available when aggregate
control mode is lacp)
Usage Select LACP timeout, i.e. the number of seconds before invalidating re-
ceived LACP information (see
). Use ”timeout short” to set
the timeout to 3 seconds and ”timeout long” to set the timeout to 90 sec-
onds.
Use ”show timeout” to view the currently configured setting.
Default values Short, i.e. 3 seconds (”no timeout”)
17.3.7
Show Status of Link Aggregates
Syntax show aggregates
Context
context
Usage Display status information for all configured aggregates. The header line
displays the aggregate information including the name, its MAC address,
and the aggregate control mode.
Each member link is listed with link status, whether or not the link is cur-
rently an active member of the aggregate, and the link state.
Aggregates using LACP also displays the LACP state (see
and partner information. Partner ID is the system id of the peer, port is the
remote port, and key is the operational key. In WeOS, the operational key is
equal to the aggregate id.
Default values Not applicable
Example In this example an aggregate (a1) is configured. Both member ports
are up, but port ’Eth 5’ is unused, since no LACP partner has been discovered
on that link.
Example
example:/#> show aggregates
Aggregate a1
MAC: 00:07:7c:00:30:b5
Type: lacp
-------------------------------------------------------------------------------
Port
Link
Active
Link State
LACP State
Partner ID
Port
Key
-------------------------------------------------------------------------------
Eth 5
UP
No
Blocking
ATTACHED
00:00:00:00:00:00
0
0
Eth 6
UP
Yes
Forwarding
DISTRIBUTING
00:07:7c:00:02:61
2
1
example:/#>
