Westermo OS Management Guide
Version 4.17.0-0
24.3.2.2 Digital-In Trigger Configuration Example
Syntax trigger digin
Context Alarm Configuration context
Usage Create a digital-in trigger, and enter the Alarm Trigger Configuration con-
text for this trigger.
Additional settings for digital-in triggers are listed below.
❼ Sensor: By default, digital-in sensor with ID 1 is used. Use ”show env”
(in Admin Exec context) to list available sensors, see section 7.3.50 .
❼ Condition: By default, the alarm condition is set to low. That is, high is
considered normal and low is considered an alarm situation.
❼ Enable/Disable: By default, the trigger is enabled.
❼ Severity: By default, active severity is WARNING and inactive severity
is NOTIFY.
❼ Action: By default, the trigger is mapped to the default action profile
(action 1).
Example
example:/#> configure
example:/config/#> alarm
example:/config/alarm/#> trigger digin
Created trigger 2
example:/config/alarm/trigger-2/#> end
example:/config/alarm/#> show
Trigger
Type Enabled Action Source
==============================================
1 power YES 1 1 2
2 digin YES 1 1
Action Targets
===============================================================================
1 snmp log led digout
===============================================================================
Summary alarm traps: Disabled
example:/config/alarm/#>
556 ➞ 2015 Westermo Teleindustri AB
