119
Modifying an SCO UNIX application monitor
Authorized users can modify all parameters except the IP address of an SCO UNIX application monitor.
When the IP address of a monitored SCO UNIX host changes, operators must add a new application
monitor for the host. The new application monitor cannot inherit the history data from the previous
application monitor.
To modify an SCO UNIX application monitor:
1. Click the Resource tab.
2. From the navigation tree, select Application Manager > Application Monitor.
The application monitor list page displays all application monitors.
3. Click the Modify icon for the SCO UNIX application monitor you want to modify.
The page for modifying the SCO UNIX application monitor appears.
4. Modify the following parameters:
{
IP Address—Cannot be modified.
{
Name—Enter a unique application monitor name. H3C recommends naming the application
monitor as Application name_host IP address.
{
Use Template—Select Enable or Disable from the list.
{
Template—Click the Configure link next to the Template field to select an existing template.
The Template field is automatically populated with the name of the selected template. For more
information about configuring application templates, see " 6 Configuration management ." This
field appears only when you select Enable from the Use Template list.
{
Description—Enter a description for the application monitor.
{
Polling Interval (min)—Select a polling interval for the application monitor. Available options
include 1, 2, 3, 4, 5, 10, 20, and 30. The default polling interval is 5 minutes. A shorter polling
interval provides more accurate real-time data but consumes more system resources. This field is
available only when you select Disable from the Use Template list.
{
Monitor Type—Select the protocol (SSH or Telnet) through which APM monitors the SCO UNIX
application, and then click the
Configure link to configure related parameters. This field is
available only when you select Disable from the Use Template list.
SSH parameters
− Edit SSH Parameters—Select this option if you want to manually configure SSH parameters
for APM. Make sure the SSH settings are the same as those on SCO UNIX.
− Select an Existing Template—Select this option if you want to select an existing SSH
template for APM. For information about setting SSH parameter templates, see H3C IMC
Base Platform Administrator Guide.
− Authentication Mode—Select the authentication mode for SSH users. Options include
Password, Private Key, Password + Private Key, Password + Super Password, Private Key +
Super Password, and Password + Private Key + Super Password. The following parameters
to be configured vary with authentication modes.
− Username—Enter the SSH username. The user must have the SCO UNIX administrator's
privilege.
− Password—Enter the password of the SSH user.
− Private Key File—Enter the directory of the SSH private key file or browse to the file.
