Fault Summary Reports
BESTCOMSPlus Navigation Path: Metering Explorer, Reports, Fault Records
HMI Navigation Path: Metering Explorer, Reports, Fault Reports
Chapter Reference: Fault Reporting
Reset “new” fault summary directory records to “0” by using the Metering Explorer in BESTCOMSPlus to
open the Reports, Fault Records screen and clicking on the Reset button. Write access is required. Verify
the new faults are “0” by clicking on the Refresh button. Refer to the
Fault Reporting
chapter for setting
details.
Sequence of Events Recorder (SER)
BESTCOMSPlus Navigation Path: Metering Explorer, Reports, Sequence of Events
HMI Navigation Path: Not available through the front panel
Chapter Reference: Sequence of Events
Reset the “new” SER records counter to “0” by using the Metering Explorer in BESTCOMSPlus to open
the Reports, Sequence of Events screen and clicking on the Clear button. Write access is required. Verify
that the new records are “0” by clicking on the Download button. Refer to the
setting details.
Just Prior to Energizing - Report Documentation
After completing the previous steps, use the Metering Explorer in BESTCOMSPlus to open the Status
tree branch. Capture and save the information for Inputs, Outputs, Alarms, Targets, and Digital Points.
This report should be kept in a permanent record file of the device so the data can be used for
comparison in future maintenance procedures.
Also, save the entire settings record for future reference by using BESTCOMSPlus and selecting
Download Settings and Logic from the Communication pull-down menu. After settings and logic are
downloaded into BESTCOMSPlus memory, select Save from the File pull-down menu. Use this record
during the maintenance cycle or during the analysis of an operation to verify that the “as found” settings
are exactly as left during the commissioning process.
Refer to the related reporting and alarms chapters and the
chapter.
In Service Readings
After energizing the equipment, use the Metering Explorer in BESTCOMSPlus to verify the following
analog metering values.
•
Secondary voltage and current to verify VT and CT ratios.
•
Polarity of energy readings to verify polarity of VT and CT connections.
•
I2 and V2 to verify proper phase-sequence connections.
•
Anything else that the user may find helpful.
Save this record along with the status record mentioned earlier for future reference.
