9424200996 Rev L
447
Panel Display
64 by 128 dot pixels LCD with LED backlight.
Operating Temperature ............................................. –40 to 70
°C (–40 to 158°F). Display contrast
adjustment may be impaired below –20
°C (–4°F).
Temperature
Operating Temperature Range .................................
–40°C to 70°C (–40°F to 158°F)*
Storage Temperature Range ....................................
–40°C to 70°C (–40°F to 158°F)
* Display is inoperative below –20°C (–4°F)
Isolation
Meets IEC 255-5 and exceeds IEEE C37.90 one minute dielectric test as follows:
All Circuits to Ground
* .............................................. 2,828 Vdc
Input Circuits to Output Circuits ................................ 2,000 Vac or 2,828 Vdc
Communication Ports to Ground ............................... 700 Vdc for one minute
* Excludes communication ports.
Standards
IEC Standards
IEC 60068-1:
Environmental Testing Part 1: General and Guidance. Temperature Test
IEC 60068-2-1: Basic Environmental Testing Procedures, Part 2: Tests - Test Ad: Cold (Type Test)
IEC 60068-2-2: Basic Environmental Testing Procedures, Part 2: Tests - Test Bd: Dry Heat (Type Test)
IEC 60068-2-28: Environmental Testing Part 2: Testing-Guidance for Damp Heat Tests
IEC 60068-2-38: Composite Temperature/Humidity Cyclic Test
IEC 60255-4:
Single Input Energizing Quantity Measuring Relays with Dependent Specified Time
IEC 60255-5:
Electrical Insulation Tests for Electrical Relays. Dielectric Test and Impulse Test
IEC 60255-6:
Electrical Relays - Measuring Relays and Protection Equipment
IEC 60255-21-1: Vibration, Shock, Bump, and Seismic Tests on Measuring Relays and Protective
Equipment (Section 1 - Vibration Test - Sinusoidal). Class 1
IEC 60255-21-2: Vibration, Shock, Bump, and Seismic Tests on Measuring Relays and Protective
Equipment (Section 2 - Shock and Bump Test - Sinusoidal). Class 1
IEEE Standards
IEEE Std C37.90.1-2002 - IEEE Standard Surge Withstand Capability (SWC) Tests for Relays and Relay
Systems Associated with Electric Power Apparatus
IEEE Std C37.90.2-2004 - IEEE Standard Withstand Capability of Relay Systems to Radiated
Electromagnetic Interference from Transceivers
IEEE Std C37.90.3-2001 - IEEE Standard Electrostatic Discharge Test for Protective Relays
CE Compliance
This product has been evaluated and complies with the relevant essential requirements set forth by the
EU legislation.
EC Directives:
•
LVD 2006/95/EC
•
EMC 2004/108/EC
Harmonized standards used for evaluation:
BE1-11m
Specifications
