11-24
VLAN Configuration Mode.
Default:
The default VLAN name is vlanXXX, where xxx is VID.
Usage Guide:
The switch can specify names for different VLANs, making it easier for users to identify and manage
VLANs.
Examples:
Specify the name of VLAN100 as TestVlan.
Switch(Config-Vlan100)#name TestVlan
11.1.10 private-vlan
Command:
private-vlan {primary | isolated | community}
no private-vlan
Function:
Configure current VLAN to Private VLAN. The “no private-vlan” command cancels the Private
VLAN configuration.
Parameter:
primary set current VLAN to Primary VLAN,
isolated set current VLAN to Isolated VLAN,
community set current VLAN to Community VLAN.
Command Mode:
VLAN mode
Default:
Private VLAN is not configured by default.
Usage Guide:
There are three Private VLANs: Primary VLAN, Isolated VLAN and Community VLAN. Ports in
Primary there are three Private VLANs: Primary VLAN, Isolated VLAN and Community VLAN can
communicate with ports of Isolated VLAN and Community VLAN related to this Primary VLAN; Ports
in Isolated VLAN are isolated between each other and only communicate with ports in Primary VLAN
they related to; ports in Community VLAN can communicate both with each other and with Primary
VLAN ports they related to; there is no communication between ports in Community VLAN and port
in Isolated VLAN.
Only VLANs containing empty Ethernet ports can be set to Private VLAN, and only the Private
VLANs configured with associated private relationships can set the Access Ethernet ports their
member ports. Normal VLAN will clear its Ethernet ports when set to Private VLAN.
It is to be noted Private VLAN messages will not be transmitted by GVRP.
Example:
Set VLAN100, 200, 300 to private vlans, with respectively primary, Isolated, Community types.
Switch(config)#vlan 100
