XGS3 Command Guide
38-65
Nexthop Neighbor
Next hop neighbor
Metric
Routing metric value
Uptime
Routing uptime
Exptime
Routing expire time
38.8 Commands for DCSCM
38.8.1 access-list (Multicast Destination Control)
Command: access-list <6000-7999> {deny|permit} ip {{<source> <source-wildcard>}|{host
<source-host-ip>}|any-source} {{<destination>
<destination-wildcard>}|{host-destination <destination-host-ip>}|any-destination}
no access-list <6000-7999> {deny|permit} ip {{<source> <source-wildcard>}|{host
<source-host-ip>}|any} {{<destination> <destination-wildcard>}|{host-destination
<destination-host-ip>}|any-destination}
Function: Configure destination control multicast access-list, the “no access-list <6000-7999>
{deny|permit} ip {{<source> <source-wildcard>}|{host <source-host-ip>}|any-source}
{{<destination> <destination-wildcard>}|{host-destination
<destination-host-ip>}|any-destination}” command deletes the access-list.
Parameter: <6000-7999>: destination control access-list number.
{deny|permit}: deny or permit.
<source>: multicast source address.
<source-wildcard>: multicast source address wildcard character..
<source-host-ip>: multicast source host address.
<destination>: multicast destination address.
<destination-wildcard>: multicast destination address wildcard character.
<destination-host-ip>: multicast destination host address
Default: None
Command Mode: Global Mode
Usage Guide: ACL of Multicast destination control list item is controlled by specifical ACL number from
6000 to 7999, the command applies to configure this ACL. ACL of Multicast destination control only
needs to configure source IP address and destination IP address controlled (group IP address), the
configuration mode is basically the same to other ACLs, and use wildcard character to configure address
range, and also specify a host address or all address. Remarkable, “all address” is 224.0.0.0/4 according
to group IP address, not 0.0.0.0/0 in other access-list.
Example:
Switch(config)#
