Sigma II User’s Manual
Chapter 7: Using the Digital Operator
7 - 12
Changing Function Selection Parameter Settings
Using the Hand-held Digital Operator
1.
Press the DSPL/SET key to select the parameter setting mode.
2.
Select the parameter number to be set.
Press the Left Arrow or Right Arrow key to select the digit. The selected
digit will flash.
Press the Up Arrow or Down Arrow key to change the value. (Pn000 is
selected in this example.)
3.
Press the DATA/ENTER key to display the current data of the parameter selected
in the above step 2.
4.
Press the Left Arrow or Right Arrow key to select the digit.
5.
Press the Up Arrow or Down Arrow key to select the value defined as a
function setting for the selected digit.
Repeat the above steps 4 and 5 for changing the data as required.
6.
Press the DATA/ENTER key to save the data. The display will flash.
Digit to be se
Digit to be set
Digit to be set
