Yaskawa Sigma II Series Servo System User Manual
Page 365
Advertising
Sigma II User’s Manual
Chapter 8: Ratings and Characteristics
8 - 35
*1
Allowable regenerative frequency is the number of times the servomotor is allowed to accelerate and
decelerate through a 0rpm
→ maximum motor speed → 0rpm cycle in a minute.
Note:
Refer to 5.6 Selecting a Regenerative Resistor for more details on allowable regenerative energy
and frequency.
Voltage
Three-phase 400V
Servo Amplifier Model
SGDH-
05DE
10DE
15DE
20AE
30DE
SGMSH Series
App
lic
abl
e
Serv
omo
tor
Model
SGMUH-
—
10D
15D
—
30D
Capacity
(kW)
—
1.0
1.5
—
2.9
Motor
Speed
(rpm)
Rated 6000/maximum 6000
Applicable
Encoder
Standard: 17-bit incremental encoder
Continuous
Output Current
A
rms
—
2.7
4.1
—
8.1
Maximum
Output Current
A
rms
—
8.5
14
—
28
Allowable
Regenerative
Frequency
*1
(times/min)
—
27
19
—
13
