Advanced Operation
7 - 2
7.1 Open-loop Vector Control
The functions that can be used with open-loop vector control are listed in Table 7.1. Details on functions that are
specific to open-loop vector control (i.e. those marked with a *) are provided in the following table.
Table 7.1 Open-loop Vector Control Functions
Comments
Control
Method
Group
Function
V/
f
V/
fw
/P
G
Open
-loop
Ve
ctor
F
lux
Ve
ctor
b1
Sequence
Settings such as the reference input method
f f f f
b2
DC Injection Braking
DC injection braking function settings
f f f f
b3
Speed Search
Speed search function settings
f f f f
b4
Delay Timers
Timer function settings
f f f f
b Application
b5
PID Control
PID control settings
f f f f
b Application
b6
Dwell Functions
Acceleration/deceleration time dwell function settings
f f f f
b7
Droop Control
Not used. (Can’t be set.)
x x x
f
b8
Energy Saving
Not used. (Can’t be set.)
f f
x x
b9
Zero Servo
Not used. (Can’t be set.)
x x x
f
C1
Accel/Decel
Acceleration/deceleration time settings
f f f f
C2
S-Curve Acc/Dec
S-curve characteristics for acceleration/deceleration times
f f f f
C3
Motor-Slip Compensation
Slip compensation function settings
f f f f
C Tuning
C4
Torque Compensation
Torque compensation function settings
f f f
x
C Tuning
C5
Speed Controls
Not used. (Can’t be set.)
x
f
x
f
C6
Carrier Frequency
Carrier frequency settings
f f f f
C7
Hunting Prevention
Not used. (Can’t be set.)
f f
x x
C8
Factory Tuning
* Adjustment for open-loop vector control
x x
f f
d1
Preset Reference
Frequency reference settings (when using Operator)
f f f f
d2
Reference Limits
Frequency upper and lower limit settings
f f f f
d Reference
d3
Jump Frequencies
Prohibited frequency settings
f f f f
d Reference
d4
Reference Frequency Hold
Function
Up/Down, Accel/Decel stop hold frequency setting
f f f f
d5
Torque Control
Not used. (Can’t be set.)
x x x
f
E1
V/f Pattern
* Motor constant settings
f f f f
E2
Motor Setup
Motor constant settings
(Motor constants are set by the autotuning function.)
f f f f
E Motor
E3
Motor 2 Control Methods
Control method settings for motor 2.
f f f f
E4
Motor 2 V/f Characteristics
V/f characteristics settings for motor 2.
f f f f
E5
Motor 2 Motor Constants
Motor constant settings for motor 2.
f f f f
F1
PG speed control card set-
tings
User constant settings for a PG Card
x
f
x
f
F2
Analog Reference Card AI
User constant settings for an Analog Reference Card
f f f f
F3
Digital Reference Card DI
User constant settings for a Digital Reference Card
f f f f
F4
Analog Monitor Card AO
User constant settings for an Analog Monitor Card
f f f f
F Options
F5
Digital Output Card DO
User constant settings for a Digital Output Card
f f f f
F Options
F6
Digital Output Card DO
User constant settings for a Digital Output Card
f f f f
F7
Pulse Monitor Card PO
User constant settings for a Pulse Monitor Card
f f f f
F8
SI-F/SI-G Transmission
Card
User constant settings for a Transmission Card
f f f f
F9
CP-916B Transmission
Card
User constant settings for a Transmission Card
f f f f
