120
• When using dual resizer effects, the frame delay mode
setting is disabled on the two target keys.
• When the frame delay mode setting is enabled, the video
has a one-frame delay.
Matte color mixing for key edge fill
If [Matte] is selected for the edge fill of a border, drop
border, or shadow, you can create a combination of color
1 and color 2 using a wipe pattern generated by the
dedicated pattern generator.
1
In the <Edge Fill> group of the M/E-1 >Key1 >Edge
menu (1112), select [Matte] and press [Matte Adjust].
The Matte Adjust menu (1112.1) appears.
2
In the <Edge Matte> group, press [Mix Color].
3
Set the following parameters.
a) The patterns are the same as standard wipe patterns 1 to 24.
You can also make a pattern selection by pressing
[Mix Pattern Select] in the Matte Adjust menu to
display the Mix Ptn Select menu (1112.2).
Press the desired pattern (1 to 24) to select it, and set
the [Size] and [Soft] parameters.
4
When adjusting color 1 and 2, select [Color 1] and
[Color 2], respectively, then adjust the following
parameters.
5
Set pattern modifiers, as required.
When selecting [Position] and setting the pattern
position
a) See page 147 .
When selecting [Multi] and replicating the pattern
a) See page 149 .
When selecting [Aspect] and adjusting the pattern
aspect ratio
a) See page 148 .
When selecting [Angle] in the <Rotation> group
and slanting the pattern
a) See page 148 .
When selecting [Speed] in the <Rotation> group
and rotating the pattern at a constant speed
a) See page 148 .
6
To interchange color 1 and color 2, press the [Color
Invert] button, turning it on.
Applying the zabton effect
1
In the M/E-1 >Key1 >Edge menu (1112), press
[Zabton], turning it on.
2
Set the following parameters.
If [Mask Pattern] is selected in step 4 and [Box] is
selected for the main mask, you cannot change the
[Size] parameter. Set it in the M/E-1 >Key1 >Main
Mask menu (1113).
3
Press [Zabton Adjust].
The Zabton Adjust menu (1112.3) appears.
No. Parameter Adjustment
1 Size Pattern size
2 Soft Degree of softness of pattern edge
3 Pattern Pattern number
a)
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
No. Parameter Adjustment
1 Position H Horizontal position a)
2 Position V Vertical position
a)
No. Parameter Adjustment
1 H Multi Number of repetitions of pattern
horizontally
2 V Multi Number of repetitions of pattern
vertically
3 Invert Type Replication layout
a)
No. Parameter Adjustment
1 Aspect Aspect ratio
a)
No. Parameter Adjustment
1 Angle Rotation angle of pattern
a)
No. Parameter Adjustment
1 Speed Rotation speed of pattern
a)
No. Parameter Adjustment
1 Size Pattern size
2 Soft Degree of softness of pattern edge
3 Density Density
Note
