Sony GP-X1EM Grip Extension - Manual (Page 405)

405
1
Connect a removable drive to the DEVICE connector
of the menu panel.
2
In the Engineering Setup >System >Maintenance
menu (7317), select the removable drive.
3
In the <USB Storage Device> group, press [Format].
4
Check the message, then press [Yes].
Setting a Removable Drive as the
Primary Device
This sets the removable drive as the primary device.
When a removable drive is not specified as the primary
device, [Removable Drive] cannot be specified for
operation in the File menu. Always configure this item.
1
In the Engineering Setup >System >Maintenance
menu (7317), select the removable drive.
2
In the <USB Storage Device> group, press [Set
Primary].
To set as the primary device automatically
In the <USB Storage Device> group, press [Auto Detect].
Initializing the Local Drive
“Local Drive” refers to the internal flash memory drive.
If the local drive becomes corrupted, format the drive.
1
In the <Local Drive> group of the Engineering Setup
>System >Maintenance menu (7317), press [Format].
2
Check the message, then press [Yes].
Locking Setup Menu Settings
To protect data, you can inhibit operations in selected
Setup menus. Note that it is not possible to lock the Setup
Operation Lock menu.
1
In the Engineering Setup >System >Maintenance
menu (7317), press [Setup Operation Lock].
The Setup Operation Lock menu (7317.1) appears.
2
In the <VF Group> group, select the group containing
the target menu to set.
3
Select the menu candidates for locking.
To select all menus within a group, press [ALL].
You can also select a menu while it is open.
For details, see “Selecting an opened setup menu to
lock” (page 405).
4
Press [Lock Item Select].
The selected menus become candidates for locking,
and a “
” padlock icon (unlocked) appears in the
“Lock” field.
If a menu is already locked, selection of lock
candidates is not possible. Unlock the menu and then
select a lock candidate.
To deselect a lock candidate
Select a lock candidate menu, and press [Lock Item
Select].
5
Repeat steps 2 to 4 to select all lock candidates.
To deselect all lock candidates
Press [Lock Item All Clear], check the message, then
press [Yes].
6
Press [Lock].
7
Enter a password of up to 16 characters in the
keyboard window, and press [Enter].
The menus in the list of candidates are all locked. The
padlock icon changes to “
” (locked state).
To release the lock
When locked, press [Lock] and enter the password.
Changing the lock password
1
In the Engineering Setup >System >Maintenance
>Setup Operation Lock menu (7317.1), press [Change
Password].
2
Check the message, then press [Yes].
3
Follow the on-screen instructions to enter the old
password and new password.
Selecting an opened setup menu to lock
With the menu you want to lock in the open state, press
[Lock Item Select] at the lower left.
Note
Note
