426
List of utility commands and memory recall button states
The following table lists the utility commands that can be
assigned to memory recall buttons.
Command name Function Button state
Lit orange Lit dark blue
PP PGM1 ST a)
|
PP PGM4 ST
a)
Enable/disable P/P program output safe title Enabled Disabled
PP PVW ST
a)
Enable/disable P/P preview output safe title Enabled Disabled
PP CLEAN ST
a)
Enable/disable P/P clean output safe title Enabled Disabled
PP K-PVW1 ST
a)
Enable/disable P/P key preview output safe title Enabled Disabled
MEx PGM1 ST
a)
|
MEx PGM4 ST
a)
Enable/disable M/E-x program output safe title
x = 1 to 5 Enabled Disabled
MEx PVW ST a) Enable/disable M/E-x preview output safe title
x = 1 to 5 Enabled Disabled
MEx CLEAN ST
a)
Enable/disable M/E-x clean output safe title
x = 1 to 5 Enabled Disabled
MEx K-PVW1 ST
a)
Enable/disable M/E-x key preview output safe
title
x = 1 to 5 Enabled Disabled
Edit Preview ST
a)
Enable/disable edit preview output safe title Enabled Disabled
Preset ST
a)
Enable/disable preset output safe title Enabled Disabled
DME Monitor Video ST
a)
Enable/disable DME Monitor Video output safe
title Enabled Disabled
DME Monitor Key ST
a)
Enable/disable DME Monitor Key output safe
title Enabled Disabled
Aux1 ST
a)
|
Aux48 ST a)
Enable/disable AUX output (1 to 48) safe title Enabled Disabled
DCU GPI1 Test Fire
|
DCU GPI50 Test Fire
Output test trigger from DCU GPI output port
(1 to 50) Output (lit light purple
only at the instant the
button is pressed) Output assigned (lit
purple)
Macro Attachment Enbl Enable/disable macro attachment Enabled Disabled
Macro AT with Rate Enable/disable mode for storing transition rate
when registering an auto transition macro
event on the transition control block or
transition control block (simple type) Enabled Disabled
Macro AT with A/B Bus Enable/disable mode for storing A/B bus cross-
points when registering an auto transition
macro event on the transition control block or
transition control block (simple type) Enabled Disabled
Macro TL with Region Enable/disable mode for saving target regions
when registering a timeline macro event Enabled Disabled
Pre Macro Set macro attachment in pre-macro mode Can be set only while
pressed (lit) Function assigned
Post Macro Set macro attachment in post-macro mode Can be set only while
pressed (lit) Function assigned
Macro Take Resume macro execution Pause during
execution (lit purple) • Executing (lit light
purple)
• Function assigned
(gray characters on
black background)
