Sony GP-X1EM Grip Extension User Manual
Page 525
525
a) The menu recalled depends on keys assigned to the delegation buttons.
b) The menu recalled depends on which of the delegation buttons is selected.
c) When the [K-SS] button is lit amber.
a) When other than [MASTR] is selected with the region selection buttons.
b) When [MASTR] is selected with the region selection buttons.
c) When the [EFF] button and [SNAPSHOT] button is lit amber or green.
a) Memory recall buttons with an assigned utility command
a) When three-dimensional transform operation mode is enabled.
b) When the VTR/disk recorder/frame memory operation mode is enabled.
c) When the resizer operation mode is enabled.
DME WIPE
b)
M/E-1, 2, 3, 4, 5, PGM/PST >Key1, 2, 3, 4, 5, 6, 7, 8 >Transition/
Video Process >DME Wipe Adjust >1ch Pattern Select
K-SS STORE
c)
Snapshot >Key Snapshot >XX
Key fader control block
Button
Menu recalled by double-press
See page
Numeric keypad control block
Button
Menu recalled by double-press
See page
EFF
• Effect >Effect 1-99 >XX
a)
• Effect >Master Timeline >Store
b)
SNAPSHOT
• Snapshot >Snapshot >XX
a)
• Snapshot >Master Snapshot >Store
b)
SHOTBOX
Shotbox >Register >Store/Recall
MCRO
Macro >Register >XX
STORE
c)
Key Frame >Region Select
RCALL
c)
Key Frame >Region Select
Utility/shotbox control block
Button
Menu recalled by double-press
See page
TRANS RATE1 to TRANS RATE3
Misc >Transition >Key/ME/FTB
M/E1 Key1 PVW to M/E1 Key8 PVW
a)
M/E2 Key1 PVW to M/E2 Key8 PVW
a)
M/E3 Key1 PVW to M/E3 Key8 PVW
a)
M/E4 Key1 PVW to M/E4 Key8 PVW
a)
M/E5 Key1 PVW to M/E5 Key8 PVW
a)
P/P Key1 PVW to P/P Key8 PVW
a)
M/E-1, 2, 3, 4, 5, PGM/PST >Key1, 2, 3, 4, 5, 6, 7, 8 >XX
Device control block (trackball)
Button
Menu recalled by double-press
See page
CH1 to CH4
a)
DME
>XX
CH1 to CH12
b)
Device >DDR/VTR >Cueup & Play
FM1 CLIP to FM20 CLIP
Frame Memory >Clip/Still >Recall
K1RSZ to K8RSZ
c)
M/E-1, 2, 3, 4, 5, PGM/PST >Key1, 2, 3, 4, 5, 6, 7, 8 >Resizer
