494
Configuring the Serial Tally Source
Address
1
In the Engineering Setup >Router/Tally >Serial Tally
menu (7367), press [Source Assign].
The Source Assign menu (7367.1) appears.
2
In the <Serial Tally Port> group, select the target port
to set.
3
In the status area, select the bit number of the port.
4
Select the source address.
5
Press [Source Address Set].
Clearing Source Address Settings
To clear a source address setting for each bit
In the Engineering Setup >Router/Tally >Serial Tally
>Source Assign menu (7367.1), select the serial tally port
and bit number, then press [Clear].
The source address setting for the selected bit is cleared.
To clear all source address settings
In the Engineering Setup >Router/Tally >Serial Tally
>Source Assign menu (7367.1), select the serial tally port
and press [All Clear]. Check the message, then press [Yes].
All source address settings for the selected serial tally port
are cleared.
To return all source address settings to the
default
In the Engineering Setup >Router/Tally >Serial Tally
>Source Assign menu (7367.1), select the serial tally port
and press [Default Recall]. Check the message, then press
[Yes].
All source address settings for the selected serial tally port
are returned to the defaults.
No. Parameter Adjustment
2 Source Addr Source address
