446
a) Only the first number input in each group of four inputs can be set.
b) Only odd-numbered inputs can be set.
c) Inputs that are multiples of 8 minus 1 (7, 15, 23, and so on) are not
available.
For details about 3840×2160P 2SI format input settings,
see “4K format input settings” (page 446).
4K format input settings
XVS-9000 settings
When the switcher signal format is 3840×2160P 2SI or
3840×2160P SQD, only odd-numbered inputs can be set.
When the switcher signal format is 3840×2160PsF SQD,
only the first number input in each group of four inputs can
be set, in the same way as for the XVS-8000/7000/6000.
Also, when the switcher signal format is 3840×2160P 2SI
or 3840×2160P SQD and an input format converter is
used, a 3840×2160P 2SI 12G input signal is assigned to a
12G×1 input, hence the setting is available for each odd-
numbered input. For 3840×2160P 2SI 3G and
3840×2160P SQD input signals, a group of four inputs is
assigned as a group to a 4K signal, and the setting is
available for the first number input in each group of four
inputs.
When an XKS-C9111N NMI Input Board and
XKS-C9121N NMI Input and Output Board are installed,
inputs that are multiples of 8 minus 1 (7, 15, 23, and so on)
are invalid because inputs 7 and 15 on each board cannot
be used.
XVS-8000/7000/6000 settings
Four inputs are assigned as a single group to a 4K signal.
A single group comprises four inputs in numeric order
starting from the first input, and the setting is available for
the first number input in each group.
When an XKS-S8112 12G-SDI Input Board is installed,
3840×2160P 2SI 12G signals are input as a 12G×1 signal,
but the input setting is available only for the first number
input in each group of four inputs.
Dedicated inputs
On the XVS-8000, dedicated input connectors 1 to 16 can
be used by installing an XKS-S8110 SDI Input Connector
Board in slot 1.
This allows you to physically connect specific output
connectors to dedicated inputs and then select a signal
from an output connector as an input.
For details about dedicated input settings, see “Setting
Dedicated Inputs” (page 447).
• Dedicated inputs are not supported on the XVS-9000/
7000/6000.
• Only output connectors on an XKS-S8165 SDI Output
Connector Board can be used for dedicated inputs.
The following output connectors can be connected.
- Format converter output connectors 1 to 16
- Spare connectors 1 to 4
- Multi viewer output connectors 1 to 8
- Output connectors 49 to 52
Input signal format conversion
The following format converters can be used.
Internal format converter: Configurable when an
XKS-8460 Format Converter Board is installed (see
page 447) .
Input format converter: Configurable when an
XKS-S8111 SDI Input and FC Connector Board,
XKS-S8112/XKS-S9112 12G-SDI Input Board,
XKS-C8111/XKS-C9111 100G IP Input Board, or
XKS-C9121 100G IP Input and Output Board is
installed
(see page 451) .
On the XVS-9000, internal format converters are not
available.
Setting Through Mode
Through mode cannot be set for inputs whose signal
format is converted by an input format converter or inputs
with frame delay enabled.
XKS-C8111 ST2110 • 3840×2160P 2SI (Level A)
a)
• 1080P (Level A)
• 1080i
• 720P
XKS-C9111
XKS-C9121 ST2110 • 3840×2160P 2SI (Level A) b)
• 1080P (Level A)
• 1080i
• 720P
XKS-C9111N
XKS-C9121N NMI • 3840×2160P 2SI
(Level A)
b) c)
Note
Input number Setting number
1, 2, 3, 4 1
5, 6, 7, 8 5
9, 10, 11, 12 9
13, 14, 15, 16 13
(and so on) (and so on)
Board Interface Signal formats
Note
Notes
Note
Note
