Chapter
10
214
DMEs
Overview
DME (Digital Multi Effects) allows you to add three-
dimensional effects such as image movement, rotation,
magnification and shrinking, as well as a wide variety of
special effects.
Up to four DME channels are available. Multiple DME
channels can be combined, which allows you to create
advanced effects with more complexity.
About DME boards
XKS-8470 HD DME Board
This board is an HD format (1080P, 1080PsF, 1080i,
720P) DME board.
It supports DME functionality on two channels per board.
XKS-8475 DME Board
This board is a 4K format (3840×2160P 2SI) and HD
format (1080P, 1080PsF, 1080i, 720P) DME board.
It supports DME functionality on one channel in 4K
format or four channels in HD format per board.
• When the switcher signal format is 3840×2160P SQD or
3840×2160PsF SQD, the DME function cannot be used.
• The maximum number of DME boards that can be
installed on each switcher and the maximum number of
DME channels available are as follows.
a) Maximum of 4 boards in combination with XKS-8470
b) Maximum of 2 channels on the XKS-8470
• If there is a mix of both XKS-8470 and XKS-8475 in a
single switcher, only the DME function of the
XKS-8475 is available.
• If Ext Out is set as an M/E dedicated output on the
XVS-8000, DME effects cannot be used in 4K format.
For details, see “Setting the Ext Out mode” (page 461).
About Ext In inputs
The signal that is input on DME Ext In (AUX bus output)
is set using the Setup menu.
For details about Ext In settings, see “Assigning an AUX
Bus to Ext In on a DME” (page 474).
• In 4K format, the Ext In input signal cannot be used.
• On the XVS-8000, only primary input and color
background signals can be used on Ext In. However,
XKS-T8110 IP Input Connector Board input signals
cannot be used.
When a dedicated input is used, you can select the
configured signal in the Engineering Setup >Switcher
>Input >Dedicated Input Assign menu (7332.10).
About DME function restrictions
There are restrictions on the number of DME channels that
can be used and on the functions, depending on the
switcher and signal format.
For differences in functions by switcher, see “XVS-9000/
8000/7000/6000 System Configuration Comparison”
(page 526).
For details about restrictions for 4K format, see “4K
Format Restrictions” (page 528).
Notes
Switcher Number of boards Number of channels
XVS-9000 XKS-8470: 2 boards
XKS-8475:
4 boards
a)
4 channels
XVS-8000
XVS-7000 2 boards 4K format: 2 channels
HD format:
4 channels
XVS-6000 1 board 4K format: 1 channel
HD format:
4 channels
b)
Notes
