457
a) Only the first number output in each group of four outputs can be set.
b) Only odd-numbered outputs can be set.
c) Ancillary data is enabled only on odd-numbered outputs.
d) Outputs that are multiples of 8 minus 1 (7, 15, 23, and so on) are not
available.
For details about 3840×2160P 2SI format output settings,
see “4K format output settings” (page 457).
4K format output settings
XVS-9000 settings
When the switcher signal format is 3840×2160P 2SI or
3840×2160P SQD, only odd-numbered outputs can be set.
When the switcher signal format is 3840×2160PsF SQD,
only the first number output in each group of four outputs
can be set, in the same way as for the XVS-8000/7000/
6000.
Also, when the switcher signal format is 3840×2160P 2SI
or 3840×2160P SQD and an output format converter is
used, a 3840×2160P 2SI 12G output signal is assigned to a
12G×1 output, hence the setting is available for each odd-
numbered output. For 3840×2160P 2SI 3G and
3840×2160P SQD output signals, a group of four outputs
is assigned as a group to a 4K signal, and the setting is
available for the first number output in each group of four
outputs.
• When an XKS-C9121N NMI Input and Output Board is
installed, outputs that are multiples of 8 minus 1 (7, 15,
23, and so on) are invalid because outputs 7 and 15 on
each board cannot be used.
• When the switcher signal format is 3840×2160P SQD
and you assign multi viewer outputs to output connectors
81 to 96, groups of four outputs are set as a single unit.
Only the first number output (81, 85, 89, 93) in each
group of four outputs can be set.
XVS-8000/7000/6000 settings
Four outputs are assigned as a single group to a 4K signal.
A single group comprises four outputs in numeric order
starting from the first output, and the setting is available
for the first number in each group.
When XKS-S8167 12G-SDI Output Board output
connectors are set to 12G mode, 3840×2160P 2SI signals
are output as a 12G×1 signal, but the output setting is
available only for the first number output in each group of
four outputs.
M/E dedicated outputs
On the XVS-8000, M/E dedicated output connectors 1 to
16 can be used by installing an XKS-S8165 SDI Output
Connector Board in slot 2.
Two outputs (Ext Out1, Ext Out2) configured on each
switcher bank can be assigned to M/E dedicated outputs as
output signals. The switcher bank Out1 to Out4 signals can
be configured as an Ext Out output signal.
For details about M/E dedicated output settings, see
“Setting M/E Dedicated Outputs” (page 461).
• M/E dedicated outputs are not supported on the
XVS-9000/7000/6000.
• M/E dedicated outputs are enabled only when the
switcher signal format is 3840×2160P. Four M/E
dedicated outputs can be used.
• The following functions are not available on an M/E
dedicated output.
Video clips, vertical blanking, through mode, safe titles,
4:3 crop
Multi viewer output connectors settings
On the XVS-9000, multi viewer output connectors can
function as output connectors 81 to 96.
You can assign output signals to output connectors 81 to
96 in the same way as other output connectors. To use the
connectors as multi viewer output connectors, multi
viewer outputs must be assigned to output connectors 81 to
96.
For details, see “Assigning Output Signals” (page 458).
Output signal format conversion
The following format converters can be used.
XKS-C8166 ST2110 • 3840×2160P 2SI (Level A)
a)
• 1080P (Level A)
• 1080i
• 720P
XKS-C9121 ST2110 • 3840×2160P 2SI (Level A) b)
• 1080P (Level A)
• 1080i
• 720P
XKS-C9121N NMI • 3840×2160P 2SI
(Level A)
b) d)
Notes
Board Interface Signal formats Output number Setting number
1, 2, 3, 4 1
5, 6, 7, 8 5
9, 10, 11, 12 9
13, 14, 15, 16 13
(and so on) (and so on)
Note
Notes
