157
Pattern group Effect
Slide The new video slides in over the old video.
Squeeze The new video appears reduced over the old video, and is progressively enlarged to
cover it.
Split The old video splits, and the new video appears in the gap.
Door The new video moves like a door closing, and progressively covers the old video.
Flip Tumble The old video rotates about an axis and is replaced by the new video. During the
transition, the signal from the utility 2 bus of the M/E bank appears as the
background.
Mirror The new video appears over the old video as a mirror effect slides in all four
directions.
Sphere The new video appears wrapped around a sphere over the old video. Next, the
picture returns to the source video while unwrapping.
Character Trail The new video appears over the old video, as if leaving a trail. Next, the picture
gradually returns to the source from the periphery.
Wave The new video appears with a wave-like effect over the old video. Next, the picture
returns to the source video as the effect reduces.
Ripple The new video appears over the old video like outwardly moving ripples.
Page Turn The old video moves like a page turning, and the new video appears behind it.
Roll The new video unrolls like a scroll over the old video. This is a type of page turn.
Frame I/O (Frame in-out) Completed in two transitions. In the first transition, the new video appears, then on
the second transition the new video goes out and the source video returns.
P in P (Picture-in-picture) • In 1-channel mode, this completes in two transitions.
- In the first transition, the old video shrinks, and the new video appears behind it.
- In the second transition, the old video expands again until it is its original size.
• In 2-channel mode, in the first half of the transition, the old video shrinks, and the
new video appears.
- In the second half of the transition, the new video expands, and the old video
disappears.
- You can move the pattern from the current position by a relative amount.
- During the transition, the signal from the utility 2 bus of the M/E bank appears
as the background.
2D Trans (2D transform) The new video appears over the old video, while undergoing expansion, two-
dimensional rotation and translation.
3D Trans (3D transform) • In 1-channel mode, the new video appears over the old video, while undergoing
expansion, three-dimensional rotation and translation.
• In 2-channel mode, the old video changes to the new video while both undergo
expansion, three-dimensional rotation and translation.
Sparkle The new video appears over the old video with a nonlinear effect applied, such as
broken glass, explosion, or melt. Next, the source picture returns as the effect
gradually reduces.
Split Slide The new video appears in strip form while sliding interleaved in the opposite
direction over the old video.
Mosaic In the first half of the transition, a mosaic is gradually applied to the old video, then
at the 50% point the inner image changes to the new video. In the second half, the
mosaic effect on the new video is gradually reduced, returning to the original image
at 100%.
Defocus In the first half of the transition, the old video is gradually defocused, then at the 50%
point the inner image changes to the new video. In the second half, the defocusing
effect on the new video is gradually reduced, returning to the original image at
100%.
Crop Slide The old image is cropped in half and a new image appears, displaying both images
side by side. Then, the cropped images slide sideways to show only the new image.
Brick • In 2-channel mode, a brick such that the side surface is visible slides in over the
old video, then rotates so that the new video can be seen.
• In 3-channel mode, a brick appears over the old video as the image is expanding
and rotating, and switches to the new video.
