In the Engineering Setup >Panel >Config menu
(7321), press [Link/Program Button].
The Link/Program Button menu (7321.8) appears.
2
Press [Transition Module1].
The Transition Module1 menu (7321.9) appears.
3
In the <Bank Select> group, press [Main].
4
In the <Bank Select> group, select the bank of the
transition control block you want to set.
5
Set the assignment for the main bank.
For details, see “Setting Transition Control Block
Button Assignments” (page 412).
6
In the <Bank Select> group, press [Sub] and set the
assignment for the sub bank.
You can also set main and sub sides independently on the
following control blocks.
• Independent key transition control block
(see page 412)
• Flexi Pad control block (see page 412)
Setting cross-point assign tables for main/
sub
Cross-point assign tables can be set not only for the main
bank, but also for the sub bank.
You can set cross-point assign tables for the following
banks.
• M/E-1 SUB to M/E-5 SUB
• P/P SUB
On the cross-point control block, the table for the main
bank is used when the [MAIN] button in the cross-point
pad is selected, and the table for the sub bank is used when
the [SUB] button is selected.
For details, see “Selecting Cross-Point Assign Tables”
(page 417).
Enabling DME wipe operations on the sub
bank
By factory default, DME wipe operations are inhibited for
backgrounds on the sub bank.
To enable DME wipe operations, in the Engineering Setup
>Switcher >Config menu (7331), press [DME Wipe Sub
Enable], turning it on.
This setting applies to all of the M/E and PGM/PST banks.
If a DME wipe is recalled on the sub bank in a snapshot or
keyframe, the image will not be handled correctly.
Inhibiting utility 2 bus signal selection
In Multi Program 2 mode, you can inhibit other uses of the
utility 2 bus signal in order to use the signal as the
background on the sub bank.
To inhibit use, in the Engineering Setup >Panel >Config
>MP2 Main/Sub Assign menu (7321.11), press [Util 2
Inhibit], turning it on.
This setting applies to all of the M/E and PGM/PST banks.
The utility 2 bus delegation buttons on the cross-point
control block become disabled.
Inhibiting key operations for main/sub
Use the Engineering Setup >Panel >Config >Operation
Inhibit >M/E Operation Inhibit menu (7321.18).
You can inhibit key operations independently for the main
bank and sub bank.
For details, see “Inhibiting Utility 2 Bus and Key
Operations” (page 413).
Making Multi Program 2 data the recall
target in keyframes and snapshots
In the Engineering Setup >Switcher >Config menu (7331),
press [Recall M/E Config], turning it on.
When a keyframe or snapshot is stored or recalled, the
following data becomes the target.
M/E Config, PGM Config, M/E Output Assign, K-PVW
Config
For details about data, see “Setting the operating mode for
a switcher bank” (page 203) and “Assigning output
signals for Multi Program 2 mode” (page 203).
This setting applies to all of the M/E and PGM/PST banks.
M/E Config data is saved, even when [Recall M/E Config]
is disabled.
Changing the key assignment for program
output
In Multi Program 2 mode, you can change the key
assignments independently.
This section describes the settings on the M/E-1 bank as an
example.
