Keyframes
Regions
The term “region” refers to a functional block of the
system.
When saving or recalling snapshot registers and effect
registers, or creating or editing effects, you first select the
region to which the operation applies. You can also select
multiple regions simultaneously.
Classification of the regions
The regions are classified as follows.
• Master region
• The following regions
- Switcher: M/E-1 to M/E-5, PGM/PST, User1 to User8
- DME: DME ch1 to DME ch4 (inclusive of Global)
- External devices: P-Bus, Router, Device1 to
Device12, GPI, Macro
Only the regions assigned to the region selection buttons of
the numeric keypad control block can be used
simultaneously
(see page 411) .
The following DME regions are disabled, depending on
the switcher signal format.
• For 3840×2160P 2SI: DME ch3 to DME ch4 on the
XVS-8000/7000 and DME ch2 to DME ch4 on the
XVS-6000
• For 3840×2160P SQD, 3840×2160PsF SQD: DME ch1
to DME ch4
Regions applicable to keyframe operations
The above regions less the Router region.
Regions applicable to snapshot operations
The above regions less the external devices’ regions (P-
Bus, Device1 to Device12, and GPI) and the Macro region.
“User” regions
You can optionally assign the following regions to the
regions User1 to User8
(see page 443) .
The User regions shown in parenthesis are the default
assignments.
• Color backgrounds 1 and 2 (User1)
• AUX1 to AUX48 (User2)
• Frame Memory 1 to 20 (User4)
Reference region
When multiple regions are selected, only one region
appears in the displays for menu and numeric keypad
control block operations. This is called the “reference
region.”
The reference region is determined according to the
following precedence.
M/E-1 >M/E-2 >M/E-3 >M/E-4 >M/E-5 >PGM/PST
>User1 >User2 >User3 >User4 >User5 >User6 >User7
>User8 >DME ch1>DME ch2 >DME ch3 >DME ch4
>Device1 >Device2 >Device3 >Device4 >Device5
>Device6 >Device7 >Device8 >Device9 >Device10
>Device11 >Device12 >P-Bus >GPI >Router >Macro
Master region
The regions saved in a master snapshot register or master
timeline register and the register numbers saved in such
regions can be recalled at a time as the master region.
Note
