327
4
Select a register.
To select all registers, press [ALL]. To select multiple
registers, set the [Num] parameter
(see page 326) .
When multiple registers are selected, all the selected
registers are locked if the first register is not locked.
All the selected registers are unlocked if the first
register is locked.
5
Press [Lock], turning it on.
To release the lock
Select the register you want to unlock, and press [Lock],
turning it off.
Copying, moving, and swapping data
between effect registers
This section describes the procedure for copying data as an
example. You can move or swap data using a similar
procedure.
1
Open the Effect >Effect 1-99 >Copy/Merge menu
(6223).
The left side of the status area shows the register
number of the copy source, and the right side shows
the register number of the copy destination.
2
Press the region display in the upper part of the list to
display a selection window, then select the region in
the selection window.
Operation between regions
Operation between regions is possible in the following
cases.
• Two of the M/E-1, M/E-2, M/E-3, M/E-4, M/E-5,
and PGM/PST regions
• Two of the User1 to 8 regions of the same
configuration
• Two of the DME ch1 to ch4 (including Global)
regions
3
Select the source and destination registers.
To select all registers, press [ALL]. To select multiple
registers, set the [Num] parameter
(see page 326) .
4
To copy without transferring the name, in the <Copy>
group, press [W/o Name], turning it on.
5
In the <Copy> group, press [Copy].
Merging effect registers
1
Open the Effect >Effect 1-99 >Copy/Merge menu
(6223).
The left side of the status area shows a list for the
register to be placed at the back when merged. The
right side shows a list for the register to be placed at the
front when merged.
2
Press the region display in the upper part of the list to
display a selection window, then select the region in
the selection window.
3
Select the register to be at the back and the register to
be at the front after the merge.
4
Press [Merge].
Deleting data from effect registers
1
Open the Effect >Effect 1-99 >Delete menu (6226).
2
Press the region display in the upper part of the list to
display a selection window, then select the region in
the selection window.
You can select more than one region.
To select all regions, press [ALL]. To select all
switcher-related regions (M/E, P/P, User), press [SWR
ALL].
3
Press [OK].
4
Select a register.
To select all registers, press [ALL]. To select multiple
registers, set the [Num] parameter
(see page 326) .
5
Press [Delete].
Attaching a name to an effect register
1
Open the Effect >Effect 1-99 >Rename menu (6227).
2
Press the region display in the upper part of the list to
display a selection window, then select the region in
the selection window.
You can select more than one region.
To select all regions, press [ALL]. To select all
switcher-related regions (M/E, P/P, User), press [SWR
ALL].
3
Press [OK].
4
Select a register.
Note
