406
[Lock Item Select] turns red, and a padlock icon appears.
The lock candidate menu selection is reflected in the
Engineering Setup >System >Maintenance >Setup
Operation Lock menu (7317.1).
If a menu is already locked, selection of lock candidates is
not possible. In this case, [Lock Item Select] is displayed
as follows.
In the Setup Operation Lock menu (7317.1), unlock the
menu and then select a lock candidate.
Locking File Loading Operations
You can inhibit load operations for a specified file
category.
1
In the Engineering Setup >System >Maintenance
menu (7317), press [File Load Lock].
The File Load Lock menu (7317.2) appears.
2
Select the category as the candidate for locking.
To select all categories, press [ALL].
3
Press [Lock].
The selected categories become candidates for
locking. The category name display color changes to
yellow, and the “Lock” indicator is displayed in
yellow in the “Lock” field.
To deselect a lock candidate
Select a lock candidate category, and press [Lock].
4
Repeat steps 2 and 3 to select all lock candidates.
To deselect all lock candidates
Press [Clear].
5
Press [Execute].
6
Enter a password of up to 16 characters in the
keyboard window, and press [Enter].
The categories in the list of candidates are all locked.
The category name and the “Lock” indicator in the
“Lock” field change to white.
To release the lock
Select a locked category and press [Lock], then press
[Execute] and enter the password.
Changing the lock password
1
In the Engineering Setup >System >Maintenance
>File Load Lock menu (7317.2), press [Change
Password].
2
Check the message, then press [Yes].
3
Follow the on-screen instructions to enter the old
password and new password.
Enabling/Disabling SDI Output
Connectors
The signal output from the output connectors of the
XKS-S8167/XKS-S9167 12G-SDI Output Boards can be
enabled/disabled.
When disabled, no signal is output from the output
connector.
To prevent radio wave interference from occurring,
disable output connectors that do not have a cable
connected.
1
In the Engineering Setup >System >Maintenance
menu (7317), press [SDI Output Enable].
The SDI Output Enable menu (7317.3) appears.
Note
Lock Item Select button
When the displayed menu is
locked When a menu other than the
displayed menu is locked
Note
