556
Included in DME Setup
Data Saved by [Init Status Define]
Included in Panel
Included in Switcher (same as data saved in Snapshot)
In Multi Program 2 mode, M/E Config settings are saved
in Snapshot when [Recall M/E Config] is enabled, but are
not saved by [Init Status Define].
7322.6 Engineering Setup >Panel >Xpt Assign >Src Name/
Src Color All data relating to Src Name/Src Color menu
7322.14 Engineering Setup >Panel >Xpt Assign >Xpt Delay All data relating to Xpt Delay menu
7331 Engineering Setup >Switcher >Config All data relating to Config menu
7332 Engineering Setup >Switcher >Input All data relating to Input menu
7333 Engineering Setup >Switcher >Output All data relating to Output menu
7334 Engineering Setup >Switcher >Transition All data relating to Transition menu
7335 Engineering Setup >Switcher >Key/Wipe/FM All data relating to Key/Wipe/FM menu
7336 Engineering Setup >Switcher >Link All data relating to Link menu
7337 Engineering Setup >Switcher >Device Interface All data relating to Device Interface menu
Menu number Menu path Saved data
7341 Engineering Setup >DME All data relating to DME menu
Menu number Menu path Saved data
– – • Key control block delegation buttons and [AUTO DELEG] button settings
• Numeric keypad control block mode selection button settings
• Utility/shotbox control block mode selection button settings
• Delegation button settings assigned to 1st row on cross-point control block,
cross-point pad button settings ([MACRO ATTACH ENABLE], display mode
button, 1st row to 4th row delegation buttons, 1st row to 4th row cross-point
assign table selection buttons, [DUAL BKGD BUS], [ROW-1 PROT] to
[ROW-4 PROT]), cross-point pad display page numbers
• AUX bus control block bus delegation button settings, cross-point pad
button settings (display mode button, [RTR MODE], [2ND DELG], [DEST
DISP MODE], level selection buttons), cross-point pad display page
numbers
• Transition control block [KF] button settings
• Flexi Pad control block mode selection button settings, key delegation
button settings in key operation mode
6351 Snapshot >Key Snapshot
>Attribute <Recall Mode> group settings
Menu number Menu path Saved data
Note
