456
Applying the video process effect
In the <Video Process> group of the Engineering Setup
>Switcher >Input >Input FC/CCR >Input CCR menu
(7332.9), press [Video Process], turning it on.
For details about the video process, see “Applying the
video process effect” (page 192).
Applying the primary color correction
effect
In the <Primary CCR> group of the Engineering Setup
>Switcher >Input >Input FC/CCR >Input CCR menu
(7332.9), press [Primary CCR], turning it on.
For details about primary color correction settings, see
“Applying the primary color correction effect”
(page 193).
Applying the RGB clip effect
In the <RGB Clip> group of the Engineering Setup
>Switcher >Input >Input FC/CCR >Input CCR menu
(7332.9), press [RGB Clip], turning it on.
For details about RGB clip settings, see “Applying the
RGB clip effect” (page 193).
Setting the Active Area
You can set a 3840×2160 or 4096×2160 active area for
groups of four inputs when the signal format is
3840×2160P.
• On the XVS-9000, the active area cannot be set.
• [4096×2160] input signals can be selected only on AUX
bus outputs set to [4096Ч2160].
• [4096Ч2160] is supported on the XKS-S8110 SDI Input
Connector Board only.
1
In the Engineering Setup >Switcher >Input menu
(7332), press [Active Area Size].
The Active Area Size menu (7332.4) appears.
2
Select the target input to set.
3
In the <Active Area Size> group, select the active area.
3840×2160: Set to 3840Ч2160.
4096Ч2160: Set to 4096×2160.
Settings Relating to
Signal Outputs
Configures settings for outputs and format converter
outputs.
The following output connector boards can be installed in
the XVS-9000/8000/7000/6000.
• XVS-9000
• XVS-8000/7000/6000
a) Interface configured in the Engineering Setup >System >Network Config
>Net I/F Protocol menu (7311.3)
The maximum number of outputs on the XVS-9000 is 80
(40 for 4K format), or 96 (48 for 4K format) when the
multi viewer output connectors are included.
For the XVS-8000/7000/6000, the maximum number of
outputs on the XVS-8000/7000 is 48 (12 for 4K format),
and on the XVS-6000 is 24 (6 for 4K format). The
maximum number of format converter outputs is 16 (4 for
4K format).
59.94 (2×) format output signals are supported on the
XKS-S8165 SDI Output Connector Board only.
Network connector board restrictions
Only the following interface and signal format outputs are
supported, depending on the board.
Notes
Output connector board Interface
XKS-S9167 12G-SDI Output Board SDI
XKS-C9121 100G IP Input and Output
Board ST2110
XKS-C9121N NMI Input and Output Board NMI
Output connector board Interface
XKS-S8165 SDI Output Connector Board SDI
XKS-S8167 12G-SDI Output Board SDI
XKS-T8165 IP Output Connector Board NMI
XKS-Q8166 QSFP IP Output Connector
Board NMI/ST2110
a)
XKS-C8166 100G IP Output Board ST2110
Note
Board Interface Signal formats
XKS-T8165 NMI • 3840×2160P 2SI (Level A)
a)
• 1080P (Level A) b)
• 1080i
XKS-Q8166 NMI • 3840×2160P 2SI (Level A)
a)
• 1080P (Level A) b)
• 1080i
ST2110 • 1080i
c)
