The network interface settings <Net I/F Setting> group
contains the following five menus.
• Engineering Setup >System >Network Config >FEC
menu (7311.4)
FEC type setting (available for XKS-C8111/
XKS-C9111/XKS-C9121/XKS-C8166 only)
• Engineering Setup >System >Network Config >IP
Address menu (7311.2)
IP address and LSM settings (available for all network
connector boards)
• Engineering Setup >System >Network Config >Input/
Output menu (7311.5)
Functions relating to input/output and audio format
settings (available for XKS-C8111/XKS-C9111/
XKS-C9121/XKS-C8166 only)
• Engineering Setup >System >Network Config >Genlock
menu (7311.6)
Network sync settings (available for XKS-C8111/
XKS-C9111/XKS-C9121/XKS-C8166 only)
• Engineering Setup >System >Network Config >NMOS
menu (7311.7)
NMOS settings (available for XKS-C8111/XKS-C9111/
XKS-C9121/XKS-C8166 only)
If either the IP Address menu (7311.2) or NMOS menu
(7311.7) is locked using the Engineering Setup >System
>Maintenance >Setup Operation Lock menu (7317.1), the
other menu is also locked automatically.
Common operations
The following operations are common to the five menus.
To display the latest information in the status
area
The status area shows the slot number in which each
network connector board is installed and the settings of
each menu.
To update the display of the status area to the latest
information, press [Refresh].
Pressing [Refresh] in any menu updates the display of the
status area for all menus.
To select the target to set
Select the item (for example, network or input/output) that
you want to change in the status area.
To select multiple items, set the number using the [Num]
parameter. The specified number of items are selected
from the currently selected items.
To select all items in the status area, press [ALL].
To apply changes to settings
When a setting is changed, the value is displayed in yellow
in the status area.
To apply the changes, press [Execute], check the message,
then press [Yes]. The changes are applied, and the display
in the status area changes to white.
To cancel the changes, press [Clear], check the message,
then press [Yes]. The display in the status area is restored
to the state before the changes were made, and the display
changes to white.
• Pressing [Execute] for any menu applies the changes
made to settings in all menus.
• You cannot cancel the changes to settings after using
[Execute].
Network name display
The network names are displayed in the following formats
in the status area.
XVS-9000:
• Main network (LAN1): 1-1/1, 1-1/2, 1-1/3, 1-1/4
• Sub network (LAN1): 1-2/1, 1-2/2, 1-2/3, 1-2/4
• Main network (LAN2): 2-1/1, 2-1/2, 2-1/3, 2-1/4
• Sub network (LAN2): 2-2/1, 2-2/2, 2-2/3, 2-2/4
XVS-8000/7000/6000:
• Main network: 1/1, 1/2, 1/3, 1/4
• Sub network: 2/1, 2/2, 2/3, 2/4
• On the XVS-9000, the “/3” and “/4” network settings are
invalid when the signal format is 1080P or 1080i.
• On the XVS-9000, the “/4” network cannot be used
when an XKS-C9111N/XKS-C9121N is installed.
Setting the FEC type
You can set the FEC type for each network.
1
In the <Net I/F Setting> group of the Engineering
Setup >System >Network Config menu (7311), press
[FEC].
The FEC menu (7311.4) appears.
2
In the <Device> group, select the target switcher to set.
The status area shows the slot number and network
settings status.
You can check the following information.
Link Speed: Link speed (“10G×4” or “25G×4”)
FEC Type: FEC type (“RS-FEC,” “FC-FEC,” or
“None”)
Link Status: Link status (“Up” or “Down”)
3
In the status area, select the target network to set.
