140

The register name is displayed on buttons for registers with
a registered snapshot.

The button color varies as follows, according to the
register state.

Gray characters on black:

Register not containing a

saved snapshot

White characters on dark blue:

Register containing a

saved snapshot

Lit orange:

Last recalled register

Saving a key snapshot

1

In the M/E-1 bank Flexi Pad control block, press the
[KEY] button.

This switches the memory recall section to key
operation mode.

2

Press the [KEY1] button in the memory recall section.

3

While pressing the [KEY] button, press the button for
the register you want to save.

The selected button is lit orange, and the key snapshot
is saved.

If you press a button in which a key snapshot is already
saved, the existing contents of the register will be
overwritten.

Recalling a key snapshot

1

In the M/E-1 bank Flexi Pad control block, press the
[KEY] button.

This switches the memory recall section to key
operation mode.

2

Press the [KEY1] button in the memory recall section.

3

Press the button for the register you want to recall.

The selected button is lit orange, and the key snapshot
is recalled.
The recalled information varies depending on the
settings in the Snapshot >Key Snapshot >Attribute
menu (6351)

(see page 336)

.

Key Snapshot Operations (Key
Fader Control Block)

Pressing the [K-SS] button in the fader control block
switches the control block to key snapshot operation mode
for saving and recalling key snapshots.

Key fader control block

You select registers 1 to 4 using the [K-SS 1] to [K-SS 4]
buttons.
The buttons for registers that store a snapshot are lit amber,
and the button for the last recalled register is lit green.
The register name is displayed on the display for buttons
for registers with a registered snapshot.

Saving a key snapshot

1

Select the target key to operate using the key
delegation buttons.

2

Press the [K-SS] button.

The [K-SS] button lights amber, and the control block
switches to key snapshot operation mode.

3

While pressing the [K-SS STORE] button, press the
button ([K-SS 1] to [K-SS 4]) for the register you want
to save.

The selected button is lit green, and the key snapshot
is saved.

If you press a button in which a key snapshot is already
saved, the existing contents of the register will be
overwritten.

Note

Note

Key delegation buttons

UNDO button

K-SS button

Display

K-SS 1 to K-SS 4 buttons

K-SS STORE button
