197
Image Effect
An image effect is a function used to apply a DME effect
to the signal selected on the background A bus or B bus.
• When the switcher signal format is 3840×2160P SQD or
3840×2160PsF SQD, the image effect cannot be used.
• There are restrictions on the number of DME channels
that can be used and on the functions, depending on the
switcher and signal format.
For differences in functions by switcher, see “XVS-9000/
8000/7000/6000 System Configuration Comparison”
(page 526).
For details about restrictions for 4K format, see “4K
Format Restrictions” (page 528).
• An image effect cannot be set when using a background
DME wipe.
• To use the image effect function, assignment of the
[IMAGE] button for the target button row for operation
to the cross-point pad is required in the Setup menu
(see
page 435) .
• Setting an image effect introduces a one-frame delay in
the video.
This section describes setting an image effect on the
background A bus on the M/E-1 bank as an example.
Assigning a DME to a background bus
Only one DME channel can be used on each background
bus.
1
Open the M/E-1 >Misc >Image Effect menu (1172).
2
In the <Image Effect> group, select [Bkgd A].
To set background B bus, select [Bkgd B].
3
In the <DME Select> group, select the DME channel
(DME1 to DME4) to be used.
The lit colors of [DME1] to [DME4] indicate the DME
assignment.
Lit green: DME assigned to the currently selected bus
Lit amber: DME assigned to another bus or key
Not lit: Unassigned DME
To select a DME being used by another bus/key
Press [Override], turning it on, then select a DME
channel that is lit amber.
The selected DME channel becomes available, and the
button is lit green.
Setting an image effect
• The DME effect to use in the image effect must be
configured for the target DME channel for operation
beforehand.
• In flip-flop mode, interchanging the background A bus
and B bus signals also interchanges their image effect
settings at the same time.
• If an image effect is set, the number of keys that can
simultaneously use a DME (including DME wipes) on
an M/E bank is as follows.
When the signal format is 3840×2160P 2SI and the
image effect is not set, DME effects can be used on
either key 1 or key 2.
1
On the cross-point control block, press the [IMAGE]
button in the cross-point pad, turning it on.
Use the [IMAGE] button for the button row assigned
with the background A bus.
2
Select the signal on the background A bus.
The signal with the DME effect set beforehand is
output.
Notes
Note
Notes
Key to which
DME effects
are applied Image effect
setting Number of keys to which
DME effects can be
applied simultaneously
Keys 1 to 4 No setting 2
Background A
or B 1
Background A
and B 0
Keys 5 to 8 – 2
