393
12
Check the message, then press [Yes].
Configuring input/output
You can enable/disable the hitless failover function for
each board. You can also set the audio format for each
input/output.
1
In the <Net I/F Setting> group of the Engineering
Setup >System >Network Config menu (7311), press
[Input/Output].
The Input/Output menu (7311.5) appears.
2
In the <Device> group, select the target switcher to set.
The status area shows the slot number and input/output
settings status.
3
In the status area, select the target slot in which the
board is installed.
4
Enable or disable hitless failover.
You can configure hitless failover for each board.
To enable, press [Hitless Fail Over], turning it on.
To disable, press [Hitless Fail Over], turning it off.
The same setting is applied to both inputs and outputs
when an XKS-C9121 is installed.
5
In the status area, select the target input/outputs to set.
6
Set the audio format of the input/outputs.
Press [Audio Format], and select an audio format from
the pop-up window.
The following formats (sampling frequency/packet
time/number of channels) are supported.
• 48kHz/0.125ms/2ch, 4ch, 8ch, 16ch
• 48kHz/1ms/2ch, 4ch, 8ch
7
Repeat steps 3 to 6 as required.
8
Press [Execute].
9
Check the message, then press [Yes].
Configuring network synchronization
You can set network synchronization (Genlock) for each
main network and sub network.
1
In the <Net I/F Setting> group of the Engineering
Setup >System >Network Config menu (7311), press
[Genlock].
The Genlock menu (7311.6) appears.
2
In the <Device> group, select the target switcher to set.
The status area shows the slot number and network
settings status of the main and sub networks.
You can check the following information.
Genlock: Network synchronization enable/disable
Domain: Domain
Com Mode: Communication mode
3
In the status area, select the target network to set.
4
Enable/disable network synchronization.
To enable, press [Genlock], turning it on.
To disable, press [Genlock], turning it off, and skip to
step
7 .
5
Press [Domain], turning it on, and set the domain using
the following parameter.
6
In the <Communication Mode> group, select the
communication mode.
Multicast: Multicast
Mixed: Combination of multicast and unicast
7
Repeat steps 3 to 6 as required.
8
Press [Execute].
9
Check the message, then press [Yes].
Setting NMOS
The XKS-C8111/XKS-C9111/XKS-C9121/XKS-C8166
support NMOS (Networked Media Open Specifications).
To manage operations using NMOS, configure the IP
address and port number of the RDS server on each board.
Enabling NMOS will disable the LSM settings in the IP
Address menu (7311.2).
1
In the <Net I/F Setting> group of the Engineering
Setup >System >Network Config menu (7311), press
[NMOS].
The NMOS menu (7311.7) appears.
2
In the <Device> group, select the target switcher to set.
The status area shows the slot number and NMOS
settings status.
Note
No. Parameter Adjustment
4 Domain Domain (0 to 255)
Note
