248
2
Press [Glow], turning it on.
The key border function and glow function cannot be
enabled at the same time. The most recently set
function is enabled.
3
Set the following parameters.
4
Press [Matte] and set the glow color.
To invert the highlight areas
Press [Glow Invert], turning it on.
The highlight and non-highlight areas are inverted.
To mask the Glow effect with a selected pattern
Press [Mask] to open the DME >Video Modify >Mask
menu (4127), and set the type of pattern and modifiers
(see
page 248) .
When the signal format is 1080P, masking will cause the
edges to become blurred.
Mask Settings
Applying the Mask effect
1
Open the DME >Video Modify >Mask menu (4127).
2
In the <Mask> group, select the effect group you want
to apply the mask.
Effect Gp1: Posterization, Solarization, Nega, Sepia,
Mono, Contrast, Mosaic, Sketch, Metal
Effect Gp2: Defocus, Blur, Glow
3
Press [Position/Size].
4
Set the following parameters.
a) Pattern numbers 21, 24, and 304
5
To invert the mask source, press [Invert], turning it on.
6
Set the modifiers for the mask pattern as required.
When selecting [Aspect] and adjusting the pattern
aspect ratio
a) When a minus value is specified, the picture is extended in the
vertical direction. When a plus value is specified, the picture is
extended in the horizontal direction.
When selecting [Angle] in the <Rotation> group
and slanting the pattern
a) –1.00 is one rotation in the counterclockwise direction. +1.00 is one
rotation in the clockwise direction. 0.00 is no rotation.
When selecting [Speed] in the <Rotation> group
and rotating the pattern at a constant speed
a) –100.00 is four rotations per second in counterclockwise direction.
+100.00 is four rotations per second in clockwise direction. 0.00 is in
stationary state.
Notes on applying a mask effect with a DME
If [Effect Gp1] and [Effect Gp2] are simultaneously
enabled in the <Mask> group of the DME >Video Modify
>Mask menu (4127), then the border or beveled edge is
also masked.
The following describes masking using a round pattern as
an example.
Note
No. Parameter Adjustment
1 Clip Reference level for highlight
detection
2 Gain Gain level for highlights
3 Soft Softness
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
Note
No. Parameter Adjustment
1 H Horizontal position
2 V Vertical position
3 Size Size of mask
4 Soft Softness of mask
5 Pattern Pattern number
a)
No. Parameter Adjustment
1 Aspect Aspect ratio a)
No. Parameter Adjustment
1 Angle Rotation angle of pattern
a)
No. Parameter Adjustment
1 Speed Rotation speed of pattern a)
