SERVO SELECTION AND DATA SHEETS
5.6.3 Connector cont.
456
MS(D190) Series: Plug for Conduit
MS3106A20-29S (D190)
Gasket
H or less
Dimensions are mm (inches)
Shell
Size
A
B
+0
−0.38
(−0.0150)
C
¦
0.5
(¦0.0197)
D
E
¦
0.3
(¦0.0118)
G
+0.05
(+0.0020)
−0.25
(−0.0098)
J
¦
0.12
(¦0.0047)
10SL
5/8-
24UNEF-2B
22.22 (0.87)
23.3 (0.92)
9/16-
24UNEF-2A
7.5 (0.30)
12.5 (0.49)
13.49 (0.53)
20
1
1/4-
18UNEF-2B 37.28 (1.47)
34.11 (1.34)
1
1/18-
18UNEF-2A 12.16 (0.48)
26.8 (1.06)
18.26 (0.72)
Made by Daiichi Denshi Kogyo K.K.
CE02-XXBS-S
Straight Back Shell (for MS(D190))
Screw
V
O-Ring
Screw
(Portion Clamped by Wrench)
7.85 (0.31)
or more
(Effective
Screw
Length)
Dimensions are mm (inches)
Shell
Size
Part
Number
L
A
B
C
D
V
W
18
CE02-18BS-S 31 (1.22)
30.5
(1.20)
10.5
(0.41)
16.3
(0.64)
26.7
(1.05)
1-20UNEF-2B
1-20UNEF-2A
20
CE02-20BS-S 35 (1.38)
35 (1.38)
10.9
(0.41)
17.8
(0.70)
31.6
(1.24)
1
1/8-
18UNEF-2B
1
3/16-
18UNEF-2A
Made by Daiichi Denshi Kogyo K.K.
