132
Field Description
Server-MAC
MAC address of the PPPoE server.
Status
PPPoE session state:
•
IDLE—PPPoE client negotiation is not performed.
•
PADI—PADI packets have been sent. The interface is waiting for the
PADO response.
•
PADR—PADR packets have been sent. The interface is waiting for the
PADS response.
•
PPPNEG—PPP negotiation is started.
•
PPPUP—PPP negotiation is completed.
PPPoE client configuration example in the Web interface
Network requirements
Configure PPPoE client on the SecPath and enable the PPPoE client to communicate with the PPPoE server,
Figure 69 Network diagram
Configuring the PPPoE client
# Create a PPPoE client.
•
Select Network > PPPoE > Client from the navigation tree, click Add, and make the following
configurations on the page shown in
.
