30
The SecPath firewall supports only port-based VLAN.
Protocols and standards
IEEE 802.1Q, IEEE Standards for Local and Metropolitan Area Networks: Virtual Bridged Local Area
Networks
Configuring VLANs in the Web interface
Recommended configuration procedure
Task Remarks
Required.
Select either task.
Configure the untagged member ports and tagged member ports of
the VLAN, or remove ports from the VLAN.
Creating a VLAN
From the navigation tree, select Network > VLAN > VLAN to enter the page as shown in
Figure 16 VLAN configuration page
Click Add to enter the page for creating a VLAN, as shown in
Figure 17 Creating a VLAN
