425
Destination Cost Type Tag NextHop AdvRouter
3.1.2.0/24 1 Type2 1 10.2.1.1 10.5.1.1
Total Nets: 6
Intra Area: 2 Inter Area: 3 ASE: 1 NSSA: 0
NOTE:
Because SecPath A resides in a normal OSPF area, its routing table contains an external route.
4.
Configure Area1 as a Stub area:
# Configure Router A.
<RouterA> system-view
[RouterA] ospf
[RouterA-ospf-1] area 1
[RouterA-ospf-1-area-0.0.0.1] stub
[RouterA-ospf-1-area-0.0.0.1] quit
[RouterA-ospf-1] quit
# Configure SecPath A.
<SecPathA> system-view
[SecPathA] ospf
[SecPathA-ospf-1] area 1
[SecPathA-ospf-1-area-0.0.0.1] stub
[SecPathA-ospf-1-area-0.0.0.1] quit
[SecPathA-ospf-1] quit
# Display routing information on SecPath A.
[SecPathA] display ospf routing
OSPF Process 1 with Router ID 10.4.1.1
Routing Tables
Routing for Network
Destination Cost Type NextHop AdvRouter Area
0.0.0.0/0 4 Inter 10.2.1.1 10.2.1.1 0.0.0.1
10.2.1.0/24 3 Transit 10.2.1.2 10.2.1.1 0.0.0.1
10.3.1.0/24 7 Inter 10.2.1.1 10.2.1.1 0.0.0.1
10.4.1.0/24 3 Stub 10.4.1.1 10.4.1.1 0.0.0.1
10.5.1.0/24 17 Inter 10.2.1.1 10.2.1.1 0.0.0.1
10.1.1.0/24 5 Inter 10.2.1.1 10.2.1.1 0.0.0.1
Total Nets: 6
Intra Area: 2 Inter Area: 4 ASE: 0 NSSA: 0
NOTE:
After the area where SecPath A resides is configured as a Stub area, a default route takes the place of the
external route.
# Filter Type-3 LSAs out the Stub area.
[RouterA] ospf
