Page 645
620
Step
Command
Remarks
1.
Enter system view.
system-view
N/A
2.
Enter public network PIM view.
pim
N/A
3.
Enable administrative scoping.
c-bsr admin-scope
Disabled by default
2.
Configuring an admin-scoped zone boundary
The boundary of each admin-scoped zone is formed by ZBRs. Each admin-scoped zone maintains
a BSR, which serves a specific multicast group range. Multicast protocol packets (such as assert
messages and bootstrap messages) that belong to this range cannot cross the admin-scoped zone
boundary.
Perform the following configuration on routers that you want to configure as a ZBR.
To configure an admin-scoped zone boundary:
Step
Command
Remarks
1.
Enter system view.
system-view
N/A
2.
Enter interface view.
interface interface-type
interface-number
N/A
3.
Configure a multicast forwarding
boundary.
multicast boundary group-address
{ mask | mask-length }
By default, no multicast
forwarding boundary is
configured.
NOTE:
The
group-address { mask | mask-length } parameter of the multicast boundary command can be used to
specify the multicast groups an admin-scoped zone serves, in the range of 239.0.0.0/8. For more
information about multicast boundary, see
Network Management Command Reference.
3.
Configuring C-BSRs for each admin-scoped zone and the global-scoped zone
In a network with administrative scoping enabled, group-range-specific BSRs are elected from
C-BSRs. C-RPs in the network send advertisement messages to the specific BSR. The BSR
summarizes the advertisement messages to form an RP-set and advertises it to all routers in the
specific admin-scoped zone. All the routers use the same hash algorithm to get the RP address
corresponding to the specific multicast group.
Configure C-BSRs for each admin-scoped zone and the global-scoped zone.
{
Configure C-BSRs for each admin-scoped zone
Perform the following configuration on the routers that you want to configure as C-BSRs in
admin-scoped zones.
To configure a C-BSR for an admin-scoped zone:
Step
Command
Remarks
1.
Enter system view.
system-view
N/A
2.
Enter public network PIM view.
pim
N/A
3.
Configure a C-BSR for an
admin-scoped zone.
c-bsr group group-address { mask |
mask-length } [ hash-length hash-length
| priority priority ] *
No C-BSRs are configured
for an admin-scoped zone
by default.
