Page 411
386
The OSPF interface information is displayed.
Figure 258 Display OSPF interface information
Table 65 Field description
Field Description
Interface Name
Interface name.
IP Address
IP address of the interface.
In case of IP unnumbered, the IP address of the borrowed interface is displayed.
Area ID
ID of the area to which the interface belongs.
Cost
Cost for the interface.
Network Type
Network type for the interface.
DR Priority
DR priority for the interface.
State
Current state of the interface, which can be:
•
Down—Indicates that no packet is sent or received through the interface.
•
Loopback
•
Waiting—Indicates that the interface starts to send and receive Hello packets and
attempts to find the DR and BDR on the network.
•
P-2-P—Indicates that the interface will send Hello packets at the hello interval, and
attempts to establish adjacency with the peer router.
•
DR—Indicates that the router is a designated router (DR) of the network.
•
BDR—Indicates that the router backup designated router (BDR) of the network.
•
DROther—Indicates that the router is neither a DR nor a BDR of the network.
Displaying OSPF neighbor information
1.
Select Network > Routing Management >OSPF from the navigation tree.
The OSPF configuration page appears.
2.
After you complete OSPF area configurations, click Show Peer on the Show Information tab.
The OSPF neighbor information is displayed.
