364
Task Command
Remarks
Clear the statistics of a RIP
process.
reset rip process-id statistics
Available in user view
RIP version configuration example at the CLI
NOTE:
In this configuration example, either Router A or Router B is the SecPath firewall.
Network requirements
As shown in
, enable RIPv2 on all interfaces on Router A and Router B.
Figure 247 Network diagram
Configuration procedure
1.
Configure an IP address for each interface. (Details not shown)
2.
Configure basic RIP functions:
# Configure Router A.
<RouterA> system-view
[RouterA] rip
[RouterA-rip-1] network 1.0.0.0
[RouterA-rip-1] network 2.0.0.0
[RouterA-rip-1] network 3.0.0.0
# Configure Router B.
<RouterB> system-view
[RouterB] rip
[RouterB-rip-1] network 1.0.0.0
[RouterB-rip-1] network 10.0.0.0
# Display the RIP routing table on Router A.
[RouterA] display rip 1 route
Route Flags: R - RIP, T - TRIP
P - Permanent, A - Aging, S - Suppressed, G - Garbage-collect
----------------------------------------------------------------------------
Peer 1.1.1.2 on GigabitEthernet0/1
Destination/Mask Nexthop Cost Tag Flags Sec
10.0.0.0/8 1.1.1.2 1 0 RA 9
The output shows that RIPv1 uses natural mask to advertise routing information.
3.
Configure a RIP version.
