H3C Technologies H3C SecPath F1000-E User Manual
Page 867
842
Ping statistics for 10::1:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 1ms, Maximum = 5ms, Average = 2ms
The debugging information about PBR displayed on SecPath A:
<SecPathA>
*Jun 7 16:03:28:946 2009 SecPathA PBR6/7/IPv6-POLICY-ROUTING: IPv6 Policy routin
g success :
POLICY_ROUTEMAP_IPV6 : lab1, Node : 10, Packet sent with next-hop 0150::0002
*Jun 7 16:03:29:950 2009 SecPathA PBR6/7/IPv6-POLICY-ROUTING: IPv6 Policy routin
g success :
POLICY_ROUTEMAP_IPV6 : lab1, Node : 10, Packet sent with next-hop 0150::0002
*Jun 7 16:03:30:949 2009 SecPathA PBR6/7/IPv6-POLICY-ROUTING: IPv6 Policy routin
g success :
POLICY_ROUTEMAP_IPV6 : lab1, Node : 10, Packet sent with next-hop 0150::0002
*Jun 7 16:03:31:949 2009 SecPathA PBR6/7/IPv6-POLICY-ROUTING: IPv6 Policy routin
g success :
POLICY_ROUTEMAP_IPV6 : lab1, Node : 10, Packet sent with next-hop 0150::0002
The preceding information shows that SecPath A sets the next hop for the received packets to 150::2
according to PBR. The packets are forwarded via GigabitEthernet 0/2.
# Ping Loopback 0 of SecPath B from Host A, and set the data section length to 200 bytes.
C:\>ping -l 200 10::1
Pinging 10::1 with 200 bytes of data:
Reply from 10::1: time=3ms
Reply from 10::1: time=1ms
Reply from 10::1: time=2ms
Reply from 10::1: time=1ms
Ping statistics for 10::1:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 1ms, Maximum = 3ms, Average = 1ms
The debugging information about PBR displayed on SecPath A:
<SecPathA>
*Jun 7 16:06:55:615 2009 SecPathA PBR6/7/IPv6-POLICY-ROUTING: IPv6 Policy routin
g success :
POLICY_ROUTEMAP_IPV6 : lab1, Node : 20, Packet sent with next-hop 0151::0002
*Jun 7 16:06:56:621 2009 SecPathA PBR6/7/IPv6-POLICY-ROUTING: IPv6 Policy routin
g success :
POLICY_ROUTEMAP_IPV6 : lab1, Node : 20, Packet sent with next-hop 0151::0002
*Jun 7 16:06:57:621 2009 SecPathA PBR6/7/IPv6-POLICY-ROUTING: IPv6 Policy routin
g success :
POLICY_ROUTEMAP_IPV6 : lab1, Node : 20, Packet sent with next-hop 0151::0002
