Digital Operator Functions
6-
129
„ Storing MxC Set Values in the Digital Operator (READ)
To store MxC set values in the digital operator, follow the directions below.
An error may occur while saving to memory. If an error is displayed, press any key to cancel the error display
and return to the o3-01 display.
Error displays and their meanings are shown below. (Refer to Chapter 7 Errors when Using the Digital Oper-
ator Copy Function.)
Table 6.1 READ Function Procedure
Step
No.
Digital Operator Display Explanation
1 Press the MENU key, and select Advanced Programming Mode.
2 Press the DATA/ENTER key, and select the parameters monitor display.
3
Display o3-01 (Copy Function Selection) using the up arrow key and down arrow
key.
4 Press the DATA/ENTER key, and select the parameters setting display.
5 Change the set value to 1 using the up arrow key.
6 Set the changed data using the DATA/ENTER key. The READ function will start.
7
If the Read function ends normally, “READ COMPLETE” appears on the digital
operator screen.
8 The display returns to o3-01 when a key is pressed.
Error Display Meaning
You are attempting to set o3-01 to 1 while o3-02 is set to 0.
Read data length mismatch or read data error.
** Main Menu **
-ADV-
Programming
Initialization
-ADV-
A1 - 00=1
Select Language
COPY Function
-ADV-
o3 - 01=0
Copy Funtion Sel
Copy Funtion Sel
-ADV-
o3-01= 0
COPY SELECT
*0*
Copy Funtion Sel
-ADV-
o3-01= 1
MxC →OP READ
*0*
READ
-ADV-
MxC →OP READING
READ
-ADV-
READ COMPLETE
Copy Funtion Sel
-ADV-
o3 - 01 =0
COPY SELECT
*0*
PRE
READ IMPOSSIBLE
IFE
READ DATA ERROR
