Yaskawa Matrix Converter - Manual (Page 42)

2
-8
* 1. Connect the Momentary Power Loss compensation unit. Do not connect power to these terminals.
* 2. Normally not used. Do not connect power to these terminals.
Note: The wire gauge recommendations for the following conditions: continuous operation at rated current, vinyl-sheathed wire (max: 75
°C), and ambient
temperature within 30 °C.
Table 2.2 400 V Class Wire Gauges
MxC Model
CIMR-†
Terminal Symbol Terminal
Screws
Tightening
Torque
(N•m)
Possible
Wire
Gauges
mm 2 (AWG)
Recom-
mended
Wire Gauge
mm
2 (AWG)
Wire Type
ACA45P5
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3 M5 2 to 2.4 Nm
3.5 to 14
(12 to 6)
3.5
(12)
power cables,
e.g., 600 V
vinyl power
cables
r2* 2 , s2* 2 , t2* 2 , p1* 1 , n1* 1 M4
1.3 to 1.4
Nm
2 to 3.5
(14 to 12)
2
(14)
M8 9 to 10 Nm
3.5 to 22
(12 to 4)
3.5
(12)
ACA4011
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3 M5 2 to 2.4 Nm
8 to 14
(8 to 6)
8
(8)
r2* 2
, s2*
2
, t2*
2
, p1*
1
, n1*
1 M4
1.3 to 1.4
Nm
2 to 3.5
(14 to 12)
2
(14)
M8 9 to 10 Nm
8 to 22
(8 to 4)
8
(8)
ACA4022
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3 M8 9 to 10 Nm
14 to 60
(6 to 1/0)
14
(6)
r2* 2 , s2* 2 , t2* 2 , p1* 1 , n1* 1 M4
1.3 to 1.4
Nm
2 to 3.5
(14 to 12)
2
(14)
M8 9 to 10 Nm
14 to 38
(6 to 2)
14
(6)
ACA4045
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3 M8 9 to 10 Nm
38 to 60
(1 to 1/0)
38
(2)
r2 *2 , s2 *2 , t2 *2 , p1 *1 , n1 *1 M4
1.3 to 1.4
Nm
2 to 3.5
(14 to 12)
2
(14)
M8 9 to 10 Nm
22 to 60
(4 to 1/0)
22
(4)
ACA4075
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3 M10 18 to 23 Nm
100
(4/0)
100
(4/0)
r2 *2 , s2 *2 , t2 *2 , p1 *1 , n1 *1 M4
1.3 to 1.4
Nm
2 to 3.5
(14 to 12)
2
(14)
M8 9 to 10 Nm
50 to 60
(1 to 1/0)
50
(1)
ACA4110
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3
M12 32 to 40 Nm
80 to 325
(3/0 to 600)
200
(400)
30 to 200
(2 to 400)
100
(4/0)
ACA4160
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3
M12 32 to 40 Nm
80 to 325
(3/0 to 600)
200
(400)
30 to 200
(2 to 400)
100
(4/0)
