Report Time—Time at which the report was generated.
•
Description—Brief description of the report.
•
Line chart—Number of online users in the last seven days are displayed, and each day displays in
a different color.
•
Table—Online users per hour in the last seven days are listed.
Service usage report
A service usage report collects statistics about the services in use, number of users that use each service,
and the services that online users are using when a scheduled report is generated. For an example of a
service usage report, see
.
Adding a service usage report
1.
Use one of the following methods to enter the page for adding a scheduled report:
{
Click the Report tab and select Add Scheduled Report from the navigation tree.
{
Click the Report tab, select Scheduled Reports > All Scheduled Reports from the navigation tree,
and click Add.
2.
Select a template:
a.
Click Select to the right of Template Name.
b.
In the Query Template area, select Access Service Report from the Type list and click Query.
c.
Select Service Usage Report.
d.
Click OK.
3.
Input the report name in the Scheduled Report Name field.
4.
Select an operator group that can view the report.
All operators in the selected operator group can view the report.
To view operators in an operator group:
a.
Click the Operator Group Information icon to the right of the Access Right field.
The Operator Group Information window appears.
b.
On the Operator Group List area, select one or more operator groups.
All operators contained in the selected operator groups appear on the right.
c.
Click Close to the return to the page for adding a report.
5.
Specify the frequency at which the report is generated.
A scheduled report period is determined by both the schedule type and schedule time settings.
a.
Schedule Type—Contains fields such as Daily, Weekly, Monthly, Quarterly, Half Yearly, and
Yearly.
b.
Report Start Date—Enter a report start time in the format of YYYY-MM-DD, or click the Calendar
icon to select a start date.
•
If you select the Daily schedule type, reports of the previous day are generated every day. For
example, if you set the report start time to 2011-08-10, the first daily report is generated at 04:00
a.m. on 2011-08-10, and the data collected until 00:00 on the day that the report was generated
displays in the report.
•
If you select the Weekly schedule type, reports of the last seven days are generated every seven
days. For example, if you set the report start time to 2011-08-10, the first weekly report is generated
