MotionSuite™ Series Machine Controller Software Manual Chapter 12: Printing
12-16
4. Page Number
Input the starting and ending page numbers for printing. Input a starting page
number smaller than the ending page number. If the number of document pages
exceeds the range input into the starting page and ending page numbers, the doc-
ument prints from the page preceding the page number designated in the final
page.
5. Details Button
This button executes detailed selection of print items. See Item 12.2.2 “Detailed
Program Setting” for information on the Details button.
12.5.2 Detailed Motion Setting
It is necessary to set detailed printing items for any print item with a Details button
displayed on the right side. In general, detailed items are set as follows:
a. Select the Details button.
b. Set the print items in the detailed item dialogue box.
c. Select the OK button.
Detailed Motion Parameter Setting
The Motion Parameter List detail dialogue box is displayed upon selecting the Details
button. Designate either Select All or Individual Selection in this box. Motion param-
eters for all axes are printed if Select All is designated. The motion parameters of a
selected axis are printed if Individual Selection is designated. The selection method for
motion parameters is the same as that for drawing programs. See Item 12.2.2,
“Detailed Program Setting: Detailed Setting of Drawing Programs.”
Detailed Motion Program Setting
The Motion Program List dialogue box is displayed upon selecting the Details button.
Designate either Select All or Individual Selection in this box. All motion programs
are printed if Select All is designated. Selected motion programs are printed if Indi-
vidual Selection is designated. Motion program cross-reference data is printed if the
Print Cross-Reference option is checked. The selection method for motion programs
is the same as that for drawing programs. See Item 12.2.2, “Detailed Program Setting:
Detailed Setting of Drawing Programs.”
