NV9000-SE Utilities • User’s Guide 87
7. Routers
Updating Router Details
4 Click
Save
.
Or
To revert to previously saved configuration, click
Revert to Saved
.
5 Click X on the window title tab to close the table.
Updating Router Physical Levels
A physical level represents both a physical partition and a group of one or more specific signal
types in the router. Each physical level typically represents a signal type, such as AES or HD. For
more information on routers and levels, see
About Levels and Level Sets on page 112.
Router physical levels can be changed using the ‘Routers’ page accessed through the ‘Configura-
tion’ pane, or the ‘PhysLevels’ table accessed through the ‘Views’ pane.
How to update router physical levels using the ‘Routers’ page
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Configuration’ pane and then ‘Routers’. The ‘Routers’
page displays, as shown in Figure 7-21.
To narrow the list of routers that display, enter the first characters of a router name in the ‘Name
Filter’ field. The list is automatically reduced to display only routers matching that character
string.
Or
