NV9000-SE Utilities • User’s Guide 415
14. External Interfaces
Locating and Viewing Existing External Interfaces
The ‘External Interfaces Details’ page that appears depends on whether the external interface is
using an Ethernet or serial protocol, as shown in Figure 14-6 and Figure 14-7.
Figure 14-6. External Interface Page for Ethernet Protocol
Figure 14-7. External Interface Page for Serial Protocol
Each section displays specific information, as follows:
Section Field Description
External
Interface Info Name The name assigned to the external interface. The information
entered in the ‘Add External Interface’ page displays. You can
change it here at this time.
Params Special parameters to be added for specific functions or to have
special features enabled.
