NV9000-SE Utilities • User’s Guide 265
11. Control Panels
Adding a Control Panel
The ‘NV9605’ page appears:
Figure 11-15. NV9605 Page
2 In the ‘Panel Options’ section, select control panel behaviors from the drop-down listsIn the
Button Layout section
Button Definitions section
Panel Optionssection
Outputs / Inputs section
Field Option Description Related Topic
Panel Behavior Limited XY Locks control panel in X-Y mode.
Multidestination (MD) mode cannot be
accessed.
Modes of Operation
on page 357
Multi-destination Locks the control panel in MD mode. X-Y
mode cannot be accessed.
Release Mode Normal Release This control panel can only release “locks”
and “protects” set at the control panel itself
(by the assigned user). A user who has the
correct PIN can enable ‘Force Release’
temporarily, allowing the removing of
locks and protects set by any user.
Locks on page 362
and
Protect on page 363
and
Force Release on
page 360
Force Release This control panel can release locks and
protects set by any user. Miranda
recommends that you use ‘Normal
Release’ mode and assign a PIN to allow
access to the ‘Force Release’ function.
