268 Rev 3.0 • 25 Mar 10
11. Control Panels
Adding a Control Panel
6 Click
Save
.
Or
To revert to the previously saved configuration, click
Revert to Saved
.
7 Click X on the window title tab to close the page.
NV9606
The ‘NV9606’ page determines how the NV9606 control panel functions and displays. For a full
description of the control panel and functions, see
NV9606 on page 525.
The ‘NV9606’ page is divided into sections:
• Button Layout — A graphic representation of the control panel. Click on a button to assign a
function to it.
• Button Definitions — Assigns a function to the currently selected button in the ‘Button Layout’
field. The options available as definitions change depending on the options selected in the
‘Panel Options’ section.
• Outputs — The general-purpose I/O (GPIO) output connections at the rear of the control panel.
• Inputs — The general-purpose I/O (GPIO) input connections at the rear of the control panel.
• Panel Options — Specifies control panel behavior, such as the type of control panel and default
mode.
The control panel options, button layout and button definitions are configured using the ‘NV9606’
page. When saved, the configurations are communicated to the physical control panel and appear to
the operator using the control panel.
How to Configure a NV9606 Control Panel
1 Add a NV9606 control panel. (See Adding a Control Panel on page 240.)
Or
Locate the NV9606 control panel being updated. (See
How to Locate and View Existing Con-
trol Panels on page 347.)
Important When configuring the control panel, it is important to select control panel options
first. This determines the subsequent button definitions.
